| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 1 |
532185382 |
DECK SVC 50".BLACK This part replaces 532156990. Price: $549.99 |
| 2 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 2 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 3 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 4 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 5 |
532138457 |
BRACKET SWAY BAR Price: $9.99 |
| 5 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 6 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 7 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532130832. Price: $9.99 |
| 7 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 8 |
75-6490 |
LEVER ASM Price: $78.45 |
| 9 |
233-42 |
KNOB Price: $12.88 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 12 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 13 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
532137553 |
SHAFT.ASM.W/BEARING Price: $32.99 |
| 14 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 14 |
532137152 |
HOUSING.MANDREL.44/46" VENT Price: $34.99 |
| 15 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 18 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 18 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 19 |
322-3 |
SCREW-HH Price: $0.79 |
| 19 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 20 |
532123713 |
SPRING TORSION Price: $6.99 |
| 20 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 21 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532137607. Price: $2.99 |
| 22 |
532110452 |
NUT PUSH M Price: $2.99 |
| 23 |
532110509 |
SHIELD.DEFLECTOR.MOWER.50"BLK. This part replaces 532171593. Price: $27.99 |
| 23 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 24 |
63-7733 |
LH BRAKE CABLE ASM Price: $210.39 |
| 25 |
63-7732 |
RH BRAKE CABLE ASM Price: $210.39 |
| 26 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 26 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 27 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 27 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 28 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 28 |
532132823 |
IDLER SPRING SPACER Price: $5.99 |
| 29 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 29 |
75-1440-03 |
PEDAL-BRAKE, LH Price: $207.74 |
| 30 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532157722. Price: $3.99 |
| 31 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 31 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 32 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 33 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 33 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 34 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 34 |
75-3270-03 |
HUB-PIVOT, TRACTION Price: $144.73 |
| 35 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 35 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 36 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 36 |
75-2170-03 |
TUBE-CONTROL, PUMP Price: $103.73 |
| 37 |
3220-3 |
NUT-HJ Price: $0.28 |
| 37 |
532137166 |
STIFFENER ARM Price: $4.99 |
| 38 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 38 |
597024901 |
Keepers This part replaces 532173968. Price: $3.99 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 39 |
597025001 |
CLG This part replaces 532173438. Price: $22.99 |
| 40 |
323-9 |
SCREW-HH Price: $1.29 |
| 40 |
532136572 |
PULLEY.DRIVEN.44" This part replaces 532173980. Price: $27.99 |
| 42 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 43 |
532136460 |
ARM.IDLER.SEC.44" Price: $5.99 |
| 44 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 45 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 46 |
582740701 |
BOLT This part replaces 874760628. Price: $4.99 |
| 47 |
532137200 |
COVER MANDRELL Price: $21.99 |
| 48 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 49 |
532136574 |
COVER.MANDREL.LH.44" Price: $19.99 |
| 50 |
532137272 |
ARM.IDLER.PRIMARY Price: $4.99 |
| 51 |
532137273 |
SPRING.SEC.44"VEN Price: $6.99 |
| 52 |
532139245 |
PULLEY IDLER Price: $32.99 |
| 53 |
532137789 |
SHIELD IDLER Price: $4.99 |
| 54 |
532139573 |
V-BELT.PRMRY 46/50 VENT.BLK BK Price: $44.99 |
| 55 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 56 |
532138687 |
SPRING Price: $3.99 |
| 58 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 59 |
596434404 |
Bolts This part replaces 532137644. Price: $4.99 |
| 62 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 63 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 64 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 65 |
532173981 |
PULLEY IDLER FLAT MWR Price: $24.99 |
| 66 |
532173979 |
KEEPER BELT IDLER PLATED Price: $4.99 |
| 67 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 94 |
596580801 |
Bolts This part replaces 874780516. Price: $2.99 |
| 95 |
532175746 |
BRACKET ASM, ROLLER (L) Price: $7.99 |
| 96 |
531154101 |
SERVICE KIT BRACKET BRACKET AS This part replaces 532175747. Price: $12.99 |
| 97 |
819171416 |
Washer 17/32 x 7/8 x 16 Ga. Price: $3.99 |
| 98 |
532132264 |
NOSE ROLLER Price: $29.99 |
| 99 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 103 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 104 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 105 |
532156852 |
BRACKET ASSY Price: $12.99 |
| 106 |
532156853 |
BRACKET ASSY Price: $12.99 |
| 107 |
532156854 |
BRKT.ASM.GA.WHL.RH.FRONT Price: $17.99 |
| 108 |
532156856 |
BRACKET ASSY Price: $22.99 |
| 109 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872010505. Price: $2.99 |
| 110 |
596040501 |
Hardware This part replaces 873980500. Price: $2.99 |
| 112 |
734117771 |
BUSHING This part replaces 819171216. Price: $3.99 |
| 113 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110504. Price: $2.99 |
| 114 |
532153183 |
REINFORCEMENT MANDREL RING Price: $9.99 |
