| Ref | Part Number | Description |
|---|
| 1 |
69-5940 |
TUBE-HYD, LH Price: $140.26 |
| 1 |
98000129 |
NUT Price: Call Us |
| 2 |
104086X |
SUB= 104086X417 Price: Call Us |
| 2 |
340-82 |
FITTING-ELBOW, 90 DEG Price: $20.57 |
| 3 |
340-91 |
FITTING-STR Price: $36.83 |
| 3 |
8393J |
STAKE PIN TI Price: Call Us |
| 4 |
106-0211 |
HYD HOSE ASM Price: $211.85 |
| 4 |
12000036 |
KLIP RING TI Price: Call Us |
| 5 |
72110508 |
BOLT CRT Price: Call Us |
| 5 |
92-1742 |
TUBE ASM Price: $93.56 |
| 6 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 6 |
8394J |
SPRING TI Price: Call Us |
| 7 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 7 |
8392J |
LATCH BRACKET TI Price: Call Us |
| 8 |
109230X |
SPRING CRT Price: Call Us |
| 8 |
71-3880 |
CLEVIS Price: $61.78 |
| 9 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 10 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 10 |
72140506 |
BOLT Price: Call Us |
| 11 |
323-6 |
SCREW-HH Price: $0.66 |
| 11 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 12 |
10040500 |
LOCKWASHER Price: Call Us |
| 12 |
71-3810 |
COUPLING-MOTOR, HYD Price: $258.45 |
| 13 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 13 |
722110510 |
BOLT Price: Call Us |
| 14 |
124343X |
BRKT SHIELD TINE Price: Call Us |
| 14 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 15 |
104101X |
SUB= 104101X417 Price: Call Us |
| 15 |
302-39 |
FITTING-PLUG Price: $10.74 |
| 16 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 16 |
73220400 |
SUB= 50675 Price: Call Us |
| 17 |
10040400 |
LOCKWASHER Price: Call Us |
| 17 |
327-22 |
SCREW-HH Price: $4.41 |
| 18 |
69-9790 |
FRONT WHEEL ASM Price: $708.06 |
| 18 |
72040410 |
BOLT Price: Call Us |
| 19 |
102701X |
GRIP CRT Price: Call Us |
| 19 |
72-4070 |
DECAL-DANGER Price: $19.16 |
| 20 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 20 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 21 |
102156X |
SUB= 102156X500 Price: Call Us |
| 21 |
3219-5 |
NUT-HEX Price: $1.22 |
| 22 |
107-4338-03 |
DRIVE-GEAR, PLANETARY Price: $4,832.04 |
| 22 |
74930632 |
BOLT Price: Call Us |
| 23 |
251-340 |
BEARING-BALL Price: $42.56 |
| 23 |
4440J |
HINGE CRT Price: Call Us |
| 24 |
253-156 |
SEAL-OIL Price: $32.46 |
| 24 |
72140404 |
BOLT Price: Call Us |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
6712 |
J VINYL CAP TI Price: Call Us 6712 J |
| 26 |
109227X |
PAD IDLER TI Price: Call Us |
| 27 |
71-3990 |
CAP-HOUSING, BRAKE Price: $310.53 |
| 28 |
120588X |
PIN HINGE Price: Call Us |
| 28 |
71-0470 |
MIDDLE DISC ASM Price: $135.95 |
| 29 |
104082X475 |
SHIELD, SIDE Price: Call Us |
| 29 |
71-0460 |
ACTUATING DISC ASM Price: $475.59 |
| 30 |
69-5930 |
TUBE-HYD, RH Price: $140.26 |
| 31 |
71-4010-03 |
DISCONTINUED Price: Call Us |
| 32 |
253-157 |
SEAL-U CUP Price: $36.39 |
| 33 |
237-158 |
O-RING Price: $4.42 |
| 34 |
92-1741 |
TUBE ASM Price: $183.07 |
| 35 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 36 |
106-0054 |
FITTING-ELBOW, 45 DEG Price: $76.65 |
| 38 |
69-3050 |
MOTOR ASM Price: $4,239.01 |
| 39 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 40 |
325-7 |
SCREW-HH Price: $1.53 |
| 41 |
2412-104 |
CLAMP-R Price: $2.37 |
| 42 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 44 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 45 |
340-148 |
FITTING-TEE Price: $186.40 |
