| Ref | Part Number | Description |
|---|
| 1 |
3-8041 |
DISCONTINUED Price: Call Us |
| 1 |
501221101 |
Screw Price: $2.99 |
| 2 |
5-1240 |
DISCONTINUED Price: Call Us |
| 2 |
505316462 |
Diaphragm Cover Price: $12.99 |
| 3 |
322-4 |
SCREW-HH Price: $0.35 |
| 3 |
501220901 |
Metering Diaphragm Price: $14.99 |
| 4 |
5-5570 |
DISCONTINUED Price: Call Us |
| 4 |
501220801 |
Gasket Price: $3.99 |
| 5 |
501485201 |
Screw Price: $3.99 |
| 6 |
27-5560 |
DISCONTINUED Price: Call Us |
| 6 |
501222101 |
Shaft Price: $4.99 |
| 7 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 7 |
501222001 |
Lever Price: $4.99 |
| 8 |
40-9120 |
DISCONTINUED This part replaces 5-1320. Price: Call Us |
| 8 |
501222501 |
Spring Price: $3.99 |
| 9 |
3217-6 |
NUT-HEX Price: $1.19 |
| 9 |
503117001 |
Needle This part replaces 501466701. Price: $7.99 |
| 10 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 10 |
501502401 |
Governor Price: Call Us |
| 11 |
5-1686 |
ADJ ROD Price: $41.75 |
| 11 |
501485001 |
Gasket Price: $0.67 |
| 12 |
3220-3 |
NUT-HJ Price: $0.28 |
| 12 |
501821801 |
Retaining Ring Price: $6.99 |
| 13 |
282-1 |
DISCONTINUED Price: Call Us |
| 13 |
503230102 |
Washer Price: $1.99 |
| 14 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 14 |
501238801 |
Nipple Price: $11.99 |
| 15 |
3-6626 |
DISCONTINUE Price: Call Us |
| 15 |
501222401 |
Filter Price: $0.99 |
| 16 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 16 |
505316495 |
Sealing Ring Price: Call Us |
| 17 |
3-6625 |
DISCONTINUED Price: Call Us |
| 17 |
501427101 |
Bushing Price: Call Us |
| 18 |
3-6624 |
DISCONTINUED Price: Call Us |
| 18 |
501221201 |
Diaphragm Price: $7.99 |
| 19 |
3-8042 |
DISCONTINUE Price: Call Us |
| 19 |
501221301 |
Gasket Price: $3.99 |
| 20 |
3-6623 |
REEL BEARING SCREW Price: $36.51 |
| 20 |
501221401 |
Cover Price: $22.99 |
| 21 |
501220301 |
Plug Price: Call Us |
| 21 |
8-6820 |
CHAIN GUARD WA *R Price: $124.30 |
| 22 |
5-0744 |
DISCONTINUED Price: Call Us |
| 22 |
503779801 |
VALVE This part replaces 505316613. Price: $22.99 |
| 23 |
322-6 |
SCREW-HH Price: $0.45 |
| 23 |
501223001 |
Screw Price: $7.99 |
| 24 |
502012201 |
Choke Flap Price: $2.62 |
| 24 |
8-6670 |
LH BRACKET ASM Price: $108.78 |
| 25 |
5-4553 |
DISCONTINUED Price: Call Us |
| 25 |
505316602 |
Choke Shaft Price: Call Us |
| 26 |
3257-14 |
KEY Price: $6.19 |
| 26 |
501220401 |
Ball Price: $9.99 |
| 27 |
5-1241 |
DISCONTINUED Price: Call Us |
| 27 |
501222501 |
Screw Price: $3.99 |
| 28 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 28 |
505316605 |
Spring Price: $6.99 |
| 29 |
5-1286 |
DISCONTINUED Price: Call Us |
| 29 |
505316458 |
Spring Price: Call Us |
| 30 |
5-5101 |
DISCONTINUED Price: Call Us |
| 31 |
5-2186 |
REEL BEARING Price: $45.95 |
| 31 |
505316454 |
Screw Price: $17.99 |
| 32 |
5-2297 |
DISCONTINUED Price: Call Us |
| 32 |
501268501 |
Idle Adjustment Screw Price: $19.99 |
| 33 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 33 |
505316603 |
Idle Screw Price: $9.99 |
| 34 |
32964 |
Nut Price: Call Us |
| 34 |
502058301 |
Ball Price: $6.99 |
| 35 |
505316619 |
Throttle Shaft Price: Call Us |
| 36 |
5-2278 |
DISCONTINUED Price: Call Us |
| 37 |
3-6665 |
BEARING CUP BOLT Price: $10.16 |
| 37 |
505316114 |
Throttle Flap Price: $5.15 |
| 39 |
40-9130 |
DISCONTINUED This part replaces 5-5850. Price: Call Us |
| 40 |
3-8073 |
DISCONTINUED Price: Call Us |
| 41 |
5-1684-01 |
SKID WA This part replaces 5-1684. Price: $216.45 |
| 42 |
3290-212 |
WASHER-SPRING Price: $1.56 |
| 43 |
3210-1 |
SCREW-HH Price: $6.29 |
| 44 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 45 |
5-1248 |
DISCONTINUED Price: Call Us |
| 46 |
251-123 |
DISCONTINUED Price: Call Us |
| 47 |
5-2295 |
OUTBOARD BRG CUP WA Price: $85.26 |
| 48 |
8-6680 |
DISCONTINUED Price: Call Us |
| 49 |
3256-3 |
WASHER-FLAT Price: $0.49 |
