| Ref | Part Number | Description |
|---|
| 1 |
120-6272 |
HYD MOTOR ASM Price: $846.73 |
| 1 |
532412165 |
CONTROL.THROTTLE.COBRA.BLACK Price: $27.99 |
| 2 |
121-5628 |
HYDRAULIC MANIFOLD ASM Price: $2,322.99 |
| 2 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 3 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 4 |
354-79 |
CAP-DUST Price: $7.81 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 5 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 6 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 6 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 7 |
115-1794 |
SCREW-HHF Price: $1.73 |
| 8 |
340-155 |
FITTING-STRAIGHT Price: $28.90 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 10 |
117-0138 |
TUBE ASM Price: $148.55 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
117-0137 |
TUBE ASM Price: $158.39 |
| 12 |
117-0139 |
TUBE ASM Price: $126.74 |
| 13 |
110-5286 |
TUBE ASM Price: $225.07 |
| 14 |
2412-4 |
CLAMP-R Price: $4.22 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
340-72 |
FITTING-BULKHEAD, 90 DEG Price: $41.27 |
| 16 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 17 |
340-78 |
NUT-LOCK Price: $1.63 |
| 18 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 19 |
69-9010 |
WASHER Price: $1.83 |
| 20 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 21 |
125-1984 |
SPACER Price: $0.68 |
| 22 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 23 |
108-1700 |
TUBE ASM Price: $199.55 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 25 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 25 |
56-7970 |
CLAMP-TUBE Price: $10.02 |
| 26 |
108-1686 |
HOSE-HYD Price: $105.24 |
| 27 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 28 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 29 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 31 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532407545. Price: $44.99 |
| 32 |
114-0633 |
HOSE-HYD Price: $149.34 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 33 |
117-5190 |
HOSE-HYD Price: $171.44 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
106-3671 |
HOSE-HYD Price: $112.38 |
| 35 |
117-5188 |
HOSE-HYD Price: $192.82 |
| 36 |
106-3680 |
HOSE-HYD Price: $73.67 |
| 37 |
139-5995 |
GUIDE-HOSE, RH This part replaces 119-3920. Price: $32.43 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 38 |
139-5996 |
HOSE GUIDE ASM-LH This part replaces 119-3921. Price: $32.43 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 116 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
