| Ref | Part Number | Description |
|---|
| 1 |
107-0807 |
VALVE-FLUSHING, RH Price: $129.44 |
| 2 |
107-0857 |
PLUG Price: $31.81 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
107-0817 |
O RING-PLUG Price: $3.09 |
| 4 |
120-5150 |
CENTER CASE ASM Price: $2,743.66 |
| 5 |
107-0858 |
U-NUT Price: $2.71 |
| 6 |
107-0805 |
PLATE-VALVE Price: $114.64 |
| 7 |
107-0824 |
CYLINDER BLOCK ASM Price: $1,216.33 |
| 8 |
107-0830 |
PLATE-THRUST Price: $77.36 |
| 9 |
92-0765 |
PIN-PARALLEL Price: $3.03 |
| 10 |
107-0859 |
BOLT Price: $1.56 |
| 11 |
107-0858 |
U-NUT Price: $2.71 |
| 12 |
120-0008 |
CONTROL ARM KIT This part replaces 107-0831. Price: $153.36 |
| 12 |
586478501 |
ENGINE.PULLEY Price: $27.99 |
| 13 |
107-0832 |
SIDE COVER ASM Price: $444.99 |
| 14 |
107-0829 |
WASHER Price: $35.71 |
| 15 |
120-5151 |
PUMP HOUSING ASM Price: $4,033.93 |
| 15 |
597954502 |
FUEL TANKS This part replaces 532433005. Price: $109.99 |
| 16 |
107-0826 |
BEARING Price: $32.70 |
| 17 |
107-0821 |
BEARING Price: $40.03 |
| 18 |
107-0838 |
BEARING Price: $62.42 |
| 18 |
532438596 |
CAP.2.25'.VENTED.TETHER .EPA Price: $29.99 |
| 19 |
107-0860 |
BOLT Price: $2.27 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
107-0861 |
PLUG-NPTF Price: $11.67 |
| 24 |
237-79 |
O-RING This part replaces 107-0862. Price: $5.46 |
| 25 |
107-0867 |
PLUG Price: $14.59 |
| 26 |
107-0812 |
PIPE Price: $75.78 |
| 27 |
107-0852 |
CENTER CASE SEAL KIT Price: $12.50 |
| 28 |
107-0813 |
SPACER Price: $8.69 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL Price: $9.99 |
| 29 |
107-0853 |
PUMP HOUSING SEAL KIT Price: $190.09 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
107-0828 |
PLATE-SWASH Price: $639.83 |
| 31 |
107-0808 |
VALVE-BYPASS Price: $86.68 |
| 32 |
107-0804 |
VALVE-REAR Price: $414.56 |
| 33 |
107-0803 |
VALVE-FRONT Price: $414.56 |
| 34 |
107-0863 |
BOLT Price: $1.22 |
| 35 |
107-0806 |
VALVE-FLUSHING, LH Price: $129.44 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
