| Ref | Part Number | Description |
|---|
| 1 |
138-6917 |
ENGINE-YANMAR, 4TNV86CT-DTR This part replaces 120-4111. Price: $20,763.34 |
| 1 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 2 |
532132752 |
CONTROL.TH/CH.RH.BLK.FLG.26 Price: $19.99 |
| 4 |
121-3061 |
PIPE-EXHAUST Price: $77.04 |
| 4 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 5 |
121-3058 |
GASKET-EXHAUST Price: $19.54 |
| 5 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 6 |
33004-00 |
NUT-HF Price: $0.34 |
| 6 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 7 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 7 |
99-5414 |
STRAP-CLEANER, AIR Price: $48.46 |
| 8 |
99-5410 |
AIR CLEANER ASM Price: $381.32 |
| 9 |
104-3563 |
INDICATOR Price: $58.60 |
| 9 |
734115441 |
WASHER - 26X6.5X1.6 This part replaces 819101216. Price: $0.99 |
| 10 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 10 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 11 |
322-6 |
SCREW-HH Price: $0.45 |
| 12 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 12 |
532137437 |
MUFFLER.SINGLE.B&S.12HP Price: $199.99 |
| 13 |
2412-125 |
CLAMP-HOSE Price: $5.22 |
| 13 |
532101326 |
DEFL MUFFLER LTV Price: $4.01 |
| 14 |
2412-110 |
CLAMP-BAND/SCREW Price: $3.60 |
| 14 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 This part replaces 817030808. Price: $3.99 |
| 15 |
18-2130 |
CLAMP Price: $5.63 |
| 15 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 16 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 17 |
121-3060 |
FLANGE-EXHAUST Price: $113.53 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 18 |
121-3142 |
HOSE-AIR CLEANER, OUTLET Price: $83.16 |
| 20 |
120-4654 |
SCREW-HHF Price: $0.34 |
| 21 |
104-7201 |
NUT-HF Price: $0.69 |
