| Ref | Part Number | Description |
|---|
| 1 |
3219-14 |
NUT-HEX Price: $0.25 |
| 1 |
510261802 |
PLATE, OUTER BRAKE, BLACK Price: $34.99 |
| 2 |
38-1670 |
MTNG BRKT W/38-1660 Price: $16.06 |
| 2 |
510206703 |
PLATE, BRAKE LATCH, BLACK Price: $24.99 |
| 3 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 3 |
510245604 |
PLATE, DECK HEIGHT, BLK EZ Price: $44.99 |
| 4 |
3290-134 |
SCREW Price: $0.27 |
| 4 |
510240502 |
PLATE, DECK HEIGHT, BLACK Price: $14.99 |
| 5 |
38-1650 |
FUEL GAUGE Price: $185.83 |
| 5 |
855842901 |
FOOT PLATE w/DECALS Price: Call Us |
| 6 |
44-2220 |
LEAD WIRE ASM Price: $9.24 |
| 6 |
522719502 |
FOOT REST WIDE ORG Price: $139.99 |
| 7 |
233-35 |
KNOB Price: $8.06 |
| 7 |
522443302 |
MOUNT, STRUT, RT, BLK Price: $19.99 |
| 8 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 8 |
522443304 |
MOUNT, STRUT, LT, BLK Price: $349.99 |
| 9 |
218-533 |
LENS Price: $17.62 |
| 9 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 10 |
27-2360 |
SWITCH Price: $46.56 |
| 10 |
595316801 |
Bolts This part replaces 539990645. Price: $3.99 |
| 11 |
510225902 |
SUPPORT, FENDER, BLACK Price: $54.99 |
| 11 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 12 |
595316401 |
Washers This part replaces 539109554. Price: $2.99 |
| 12 |
83-0820 |
GAUGE - AMMETER This part replaces 38-1660. Price: $76.09 |
| 13 |
43-3980 |
INST PANEL DECAL Price: $32.94 |
| 13 |
589283402 |
FRAME.TUBE.RZ.MAIN.WELD.RH.ORG This part replaces 510177503. Price: $79.99 |
| 14 |
42-9190 |
GLOW LAMP (F/W & PPP) Price: $89.59 |
| 14 |
589283302 |
FRAME.TUBE.RZ.MAIN.WELD.LH.ORG This part replaces 510177403. Price: $79.99 |
| 15 |
26-6750 |
ENG TEMP SWITCH GAGE Price: $332.79 |
| 15 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 16 |
43-3970-03 |
INSTRUMENT PANEL This part replaces 43-3970. Price: $111.29 |
| 16 |
539111976 |
ENGINE BOLT, SPECIAL Price: $2.99 |
| 17 |
218-473 |
BOOT-SWITCH Price: $17.61 |
| 17 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 18 |
26-6740 |
TEMP RESET RELAY Price: $165.84 |
| 18 |
596582301 |
Washers This part replaces 539990055. Price: $2.99 |
| 19 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 19 |
6-1659 |
SWITCH & BOOT ASM Price: $78.15 |
| 20 |
596435501 |
Bolts This part replaces 539102335. Price: $3.99 |
| 21 |
43-4000 |
CIRCUIT BREAKER Price: $116.55 |
| 21 |
539977761 |
HCS 1/4C X 1 Price: $2.99 |
| 22 |
3250-17 |
SCREW-PPH Price: $1.76 |
| 22 |
596917002 |
Screws This part replaces 539110674. Price: $1.99 |
| 23 |
43-3990 |
CONTROL-THROTTLE Price: $49.39 |
| 23 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
| 24 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 24 |
522924201 |
SWIVEL Price: $7.99 |
| 25 |
43-0410 |
REGULATOR (F/W & PPP) Price: $416.45 |
| 25 |
521938102 |
Links This part replaces 521938101. Price: $12.99 |
| 26 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 26 |
580486102 |
Spacers This part replaces 515988101. Price: $3.99 |
| 27 |
43-1880 |
CONT UNIT (F/W ENG&PPP) Price: $434.93 |
| 27 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 28 |
3290-424 |
SCREW-SHH Price: $2.54 |
| 28 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 29 |
523112802 |
REINFORCEMENT PLATE BLK Price: $38.99 |
| 29 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 30 |
321-4 |
SCREW-HH Price: $0.99 |
| 30 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 31 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 31 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 32 |
3217-6 |
NUT-HEX Price: $1.19 |
| 32 |
539976938 |
CAPSCREW Price: $3.99 |
| 33 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 33 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 34 |
43-3820 |
BUZZER SPACER Price: $2.80 |
| 34 |
539101721 |
HCS 5/16C X 2-3/4 Price: $3.99 |
| 35 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 35 |
516016302 |
GUARD, REAR, ORANGE Price: $149.99 |
| 36 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 36 |
516016402 |
SUPPORT, CORNER, ORANGE Price: $37.99 |
| 37 |
3217-26 |
NUT-HEX Price: $0.25 |
| 37 |
539111786 |
RHSSNB, 1/4-20X5/8 Price: $1.99 |
| 38 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 38 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 39 |
218-515 |
BRACKET Price: $12.11 |
| 39 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 40 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 41 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 42 |
63-7590 |
RELAY Price: $78.15 |
| 43 |
70-1190 |
DISCONTINUED Price: Call Us |
| 44 |
321-6 |
SCREW-HH Price: $0.25 |
