| Ref | Part Number | Description |
|---|
| 1 |
77-3900 |
SCREW - HEX HEAD,METRIC Price: $2.85 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 2 |
74-4050 |
BRACKET - HOOD STOP*B Price: $22.69 |
| 3 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 4 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 5 |
62-1230 |
WASHER-RUBBER Price: $5.39 |
| 6 |
66-2871 |
CABLE-STOP, HOOD Price: $61.31 |
| 7 |
74-6040 |
HOSE RETURN Price: $58.26 |
| 8 |
74-4010 |
WIREFORM WA Price: $488.44 |
| 9 |
532408667 |
KEEPER BELT ENGINE Price: $9.99 |
| 9 |
77-3550 |
DISCONTINUED Price: Call Us |
| 10 |
46-6810 |
SCREW AND WASHER ASM Price: $3.49 |
| 11 |
110-4114 |
HOSE-FUEL This part replaces 55-4130. Price: $30.59 |
| 11 |
587241401 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH01 Price: $229.99 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 12 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 13 |
77-3560 |
PLUG & GASKET F/W Price: $34.33 |
| 14 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
529998404 |
FUEL TANK, 4GAL, 2.25"NECK, 20 This part replaces 532438081. Price: $199.99 |
| 15 |
74-9120 |
HOSE-OVERFLOW, RADIATOR Price: $9.97 |
| 16 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 17 |
2412-96 |
CLAMP-R Price: $3.46 |
| 18 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 19 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 20 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 20 |
532412165 |
CONTROL.THROTTLE.COBRA.BLACK Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
74-6010 |
HOSE - OVER FLOW Price: $43.63 |
| 22 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
2412-125 |
CLAMP-HOSE Price: $5.22 |
| 24 |
74-6030 |
DISCONTINUED Price: Call Us |
| 25 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 26 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 27 |
110-4107 |
HOSE-FUEL This part replaces 63-7622. Price: $7.77 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
77-3890 |
BRACKET - HOOD STOP *B Price: $40.20 |
| 29 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 30 |
32128-20 |
NUT-HF Price: $0.99 |
| 31 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 32 |
74-5930 |
DISCONTINUED Price: Call Us |
| 33 |
74-9122 |
HOSE-OVERFLOW, RADIATOR Price: $20.47 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 85 |
581636201 |
BOLT.HEX.7/16-20X3.0XGR5 Price: $4.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
