| Ref | Part Number | Description |
|---|
| 1 |
110-8785 |
HYD MOTOR ASM (CCW) Price: $1,062.27 |
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 2 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $37.99 |
| 3 |
110-8786 |
HYD MOTOR ASM (CW) Price: $1,062.27 |
| 3 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 4 |
322-9 |
SCREW-HH Price: $3.09 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 8 |
95-8783 |
TUBE ASM Price: $172.34 |
| 9 |
353-990 |
PLUG ASM Price: $10.01 |
| 9 |
532168346 |
DASH SLKSCRN. This part replaces 532171682. Price: $29.54 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $9.99 |
| 11 |
95-8784 |
TUBE ASM Price: $181.92 |
| 12 |
3274-99 |
SCREW-HSH Price: $3.04 |
| 12 |
532145660 |
CLIP Price: $2.99 |
| 13 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000-03. Price: $8.08 |
| 13 |
532172106 |
PANEL ASM, DASH RH Price: $14.99 |
| 14 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 17 |
532159639 |
HOOD.STEEL.LT.ORANGE This part replaces 532162237. Price: $64.99 |
| 18 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 18 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 20 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 20 |
532180679 |
PLATE MTG.BATTERY/FUEL TANK Price: $9.99 |
| 21 |
321-5 |
SCREW-HH Price: $0.22 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 23 |
104-7705 |
BRAKE ASM Price: $175.69 |
| 23 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 24 |
104-0485-0P |
SHIELD - WHEEL This part replaces 104-0485-03. Price: $38.89 |
| 25 |
119-8238 |
SPACER-DECK PULLEY Price: $7.49 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 26 |
114-2726 |
LEVER-BRAKE Price: $29.20 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 28 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 28 |
532179845 |
GRILLE/LENS ASM Price: $173.99 |
| 29 |
532146654 |
GRILLE.LENS This part replaces 532176645. Price: $17.99 |
| 30 |
115-6672 |
BRAKE LEVER ASM Price: $22.20 |
| 30 |
583713401 |
KIT.FENDER.PNT.STL.W/CPH. This part replaces 532181001. Price: $249.99 |
| 31 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 33 |
104-4625-03 |
SHAFT-PIVOT, BRAKE Price: $158.63 |
| 34 |
95-8683 |
BRACKET-PIVOT, BRAKE Price: $13.75 |
| 35 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 36 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 37 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
104-7706 |
E-RING, BOWED Price: $1.72 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 39 |
3274-105 |
SCREW-HSBH Price: $7.79 |
| 40 |
104-4809 |
DRUM-BRAKE Price: $58.92 |
| 41 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 52 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 53 |
532144697 |
BRACKET.GRILLE.LH Price: $4.99 |
| 54 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 Price: $3.99 |
| 55 |
532144696 |
BRACKET Price: $4.99 |
| 57 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 58 |
532174930 |
DUCT, INTAKE AIR Price: $19.99 |
| 60 |
872140606 |
Bolt - Rd. Hd. Sq. Neckiage 3/8 16 x 3/4 Price: $4.99 |
| 64 |
532154798 |
DASH LOWER Price: $17.99 |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS This part replaces 532154966. Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 206 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $7.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 212 |
532174503 |
INSERT, LENS This part replaces 532156229. Price: $22.99 |
