| Ref | Part Number | Description |
|---|
| 1 |
237-21 |
O-RING Price: $0.70 |
| 1 |
710-3033 |
BOLT Not Available Price: |
| 2 |
322-3 |
SCREW-HH Price: $0.79 |
| 2 |
712-3026 |
Nut, Hex Jam, 3/4-16 GR5 Price: $4.29 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
703-1838 |
CROSS SHAFT ASSEMBLY Not Available Price: |
| 4 |
712-3008 |
HEX JAM NUT 3/8-16 GR5 Price: $4.08 |
| 4 |
82-9330 |
BRACKET - SENSOR *R Price: $24.29 |
| 5 |
23-1840 |
BUSHING-TAPERLOCK Price: $92.22 |
| 5 |
731-3108 |
KNOB-SPEED Not Available Price: |
| 6 |
237-22 |
O-RING Price: $2.43 |
| 6 |
723-3013 |
FRICTION DISC Not Available Price: |
| 7 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 7 |
936-3022 |
BELL WASHER Not Available This part replaces 736-3022. Price: |
| 8 |
237-42 |
O-RING Price: $2.78 |
| 8 |
712-3053 |
L-NUT 1/2-20 Not Available Price: |
| 9 |
58-0070 |
DISC BRAKE ASM Price: $316.73 |
| 9 |
923-3011 |
JOINT-BALL-5/16-24 (R.H.) This part replaces 723-3011. Price: $32.80 |
| 10 |
712-3025 |
Nut, Hex Jam, 5/16-24 Price: $6.24 |
| 11 |
237-118 |
O-RING Price: $1.73 |
| 11 |
747-3018 |
CONNECTING ROD Not Available Price: |
| 12 |
58-5430 |
PISTON MOTOR ASM Price: $3,072.75 |
| 12 |
712-0237 |
Nut, Hex Center Lock, 5/16-24 This part replaces 712-0305. Price: $4.37 |
| 13 |
237-81 |
O-RING Price: $2.76 |
| 13 |
923-3012 |
Ball Joint 5/16-24 Thd. This part replaces 723-3012. Price: $37.06 |
| 14 |
912-3045 |
Hex Jam Nut 5/16 Thd. L.H. Not Available This part replaces 712-3045. Price: |
| 14 |
92-6058 |
FITTING-STR Price: $105.61 |
| 15 |
237-58 |
O-RING Price: $2.18 |
| 15 |
716-3000 |
RETAINING RING Not Available Price: |
| 16 |
323-18 |
SCREW-HH Price: $0.82 |
| 16 |
703-0198A |
CAM ASSEMBLY Not Available Price: |
| 17 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 17 |
719-3013 |
Clevis Adjustment Price: $24.95 |
| 18 |
353-949 |
O-RING Price: $3.49 |
| 18 |
912-3001 |
Nut, Jam, 3/8-24 This part replaces 712-3001. Price: $5.94 |
| 19 |
60-6990 |
WASHER Price: $4.62 |
| 19 |
703-0200 |
CONTROL ROD ASSEMBLY Not Available Price: |
| 20 |
327-3 |
SCREW-HH Price: $1.49 |
| 20 |
710-0520 |
Screw, Hex Cap, 3/8-16 x 1.5 Lg GR5 Price: $3.93 |
| 21 |
62-6400-03 |
HUB-WHEEL, DRIVE This part replaces 62-6400. Price: $3,397.53 |
| 21 |
736-0267 |
FLAT WASHER .38X.88 Price: $3.90 |
| 22 |
3247-10 |
SETSCREW Price: $0.55 |
| 22 |
703-0196 |
BRACKET-CAM PIVOT Not Available Price: |
| 23 |
3219-5 |
NUT-HEX Price: $1.22 |
| 23 |
716-0865 |
Ring, Snap, .500 Price: $3.86 |
| 24 |
58-5610 |
RIM Price: $360.43 |
| 24 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 7360272. Price: $4.37 |
| 25 |
58-5620 |
TUBE Price: $89.16 |
| 25 |
903-0194 |
DAMPER PLATE ASSEMBLY Not Available This part replaces 703-0194. Price: |
| 26 |
136-3327 |
TIRE This part replaces 63-4480. Price: $404.86 |
| 26 |
916-0115 |
SNAP RING FOR .625 DIA SHAFT Not Available This part replaces 716-0115. Price: |
| 27 |
323-20 |
SCREW-HH Price: $1.28 |
| 27 |
711-3033 |
Pin, Spring Guide Price: $13.56 |
| 28 |
58-3780 |
TUBE-SPACE Price: $25.99 |
| 28 |
932-3012 |
COMPRESSION SPRING This part replaces 732-3012. Price: $6.10 |
| 29 |
29-1060 |
BRACKET-SECONDARY Price: $135.49 |
| 32 |
58-0110-03 |
BRACKET-CALIPER, BRAKE This part replaces 58-0110. Price: $142.37 |
| 33 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 34 |
29-1070 |
LEVER ASM Price: $64.17 |
| 35 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 36 |
60-1740 |
NUT Price: $1.53 |
| 37 |
58-2300 |
LINK-BRAKE Price: $30.30 |
| 38 |
283-67 |
PIN-CLEVIS Price: $2.04 |
| 39 |
29-1080 |
BRAKE PAD Price: $66.87 |
| 40 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 41 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 42 |
82-9280 |
DISC WA Price: $599.98 |
| 43 |
340-90 |
DISCONTINUED Price: Call Us |
| 503215825 |
503215825 |
SCREW Price: $2.99 |
| 503811402 |
503811402 |
COVER Price: $22.99 |
