Cylinder/Top Cover — Parts Catalog

Ref	Part Number	Description
1	104-0000-03	PULLEY Price: $400.11
2	99-6937	FAN Price: $304.08
3	3296-29	NUT-LOCK, NI Price: $2.09
7	251-318	BEARING-BALL Price: $16.40
8	104-0001	SPACER Price: $25.45
9	104-0017	HUB This part replaces 104-0017-03. Price: $185.06
10	323-12	SCREW-HH Price: $1.14
11	63-8410	WASHER Price: $1.76
12	11-0160	ROLLER SHAFT SCREW ASM Price: $28.16
13	104-1487	BOLT-CARR Price: $3.93
14	3256-23	WASHER-PLAIN Price: $0.28
15	104-1440-03	SUPPORT-FAN Price: $395.73
16	104-0006-03	LEVER-FAN, IDLER Price: $61.11
17	3253-4	WASHER-LOCK Price: $0.25
18	98-3921	BELT Price: $16.95
19	95-3857	SCREW-HSBH Price: $4.09
20	63-8140	PULLEY-IDLER Price: $47.94
21	104-1447-03	BRACKET-FAN, SUPPORT Price: $39.88
22	3274-12	SCREW-HSH Price: $0.81
23	3253-4	WASHER-LOCK This part replaces 42-9850. Price: $0.25
24	3234-29	SCREW-HHF Price: $1.84
25	121-4600	NUT-HEX This part replaces 3296-59. Price: $0.78
26	104-1481-03	BRACKET-MOUNT, FAN Price: $58.30
27	98-4561-03	SHIELD-ALTERNATOR Price: $56.98
29	32144-14	SCREW-HWHTF Price: $4.29
30	3256-24	WASHER-FLAT Price: $0.28
31	33114-020	SCREW-HH Price: $0.28
32	322-4	SCREW-HH Price: $0.35
33	104-0007	SPACER Price: $39.26
34	322-3	SCREW-HH Price: $0.79
503218318	503218318	Screw W/Washer 5x20 Price: $2.75
531002913	531002913	Price: $13.29
531002914	531002914	Price: $33.47
531002915	531002915	Price: $4.12
531002916	531002916	Price: $95.68
531002917	531002917	Price: $4.39
