| Ref | Part Number | Description |
|---|
| 1 |
130-2709 |
COVER ASM Price: Call Us |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
108-8027 |
COVER Price: $59.41 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
130-2711 |
CONTROL-LEVEL Price: $151.93 |
| 4 |
108-8029 |
VALVE-CONTROL, AIR Price: $382.10 |
| 5 |
130-2712 |
SHOCK ABSORBER ASM Price: $300.82 |
| 6 |
130-2714 |
AIR SPRING ASM Price: $191.02 |
| 7 |
130-2716 |
AIR TUBE ASM Price: $215.90 |
| 8 |
147-1720 |
WIRE HARNESS ASM This part replaces 130-2718. Price: $160.58 |
| 8 |
587205101 |
TRAY.BATTERY BOX.FRONT Price: $14.99 |
| 9 |
130-2719 |
COMPRESSOR Price: $534.30 |
| 10 |
130-2721 |
BELLOWS ASM Price: $248.41 |
| 11 |
130-2723 |
TETHER Price: $164.48 |
| 13 |
130-2726 |
HANDLE Price: $100.26 |
| 14 |
130-2727 |
UPPER SUSPENSION KIT Price: $105.22 |
| 15 |
130-2728 |
LOWER SUSPENSION KIT Price: $136.21 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 Price: $7.99 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 Price: $7.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $17.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
501132901 |
HARNESS HARNESS..DASH.ING.ELEC Price: $59.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 582042801. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 103 |
532421747 |
HARNESS.PIGTAIL.12V.OUTLET. Price: $12.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
