| Ref | Part Number | Description |
|---|
| 1 |
121-9107 |
SPINDLE ASM Price: $48.84 |
| 2 |
32144-57 |
SCREW Price: $1.04 |
| 3 |
139-6612 |
SHAFT-SPINDLE This part replaces 120-5234. Price: $19.54 |
| 4 |
139-6613 |
SHAFT-SPINDLE This part replaces 120-5235. Price: $20.42 |
| 5 |
121-9100 |
SPROCKET Price: $34.41 |
| 6 |
130-6664 |
PULLEY-BRAKE, SPINDLE Price: $33.33 |
| 7 |
109-9505 |
WASHER-SPRING Price: $4.49 |
| 8 |
3296-19 |
NUT-HEX Price: $0.65 |
| 9 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 10 |
120-6242 |
ARM-BRAKE Price: $18.71 |
| 11 |
121-2305 |
WASHER-FRICTION, COMPOSITE Price: $2.93 |
| 12 |
138-3244 |
SPACER This part replaces 120-9490. Price: $6.35 |
| 13 |
139-1728 |
BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 14 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 15 |
322-7 |
SCREW-HH Price: $0.89 |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
126-7890 |
PULLEYS AND IDLER KIT This part replaces 131-4509. Price: $120.33 |
| 18 |
138-3232 |
BRACKET-IDLER This part replaces 120-3348. Price: $6.81 |
| 19 |
120-7024 |
SCREW-SHOULDER,HWH Price: $1.31 |
| 20 |
120-3335 |
BELT-SYNCHRONOUS Price: $61.28 |
| 21 |
120-5245-03 |
GUIDE-BELT, SPINDLE Price: $4.49 |
| 22 |
120-5236 |
ADAPTER-BLADE Price: $4.71 |
| 23 |
121-5808 |
SPRING-EXTENSION, BRAKE Price: $11.49 |
| 24 |
125-2466 |
BOLT-BLADE Price: $2.20 |
| 25 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 26 |
120-7082 |
PULLEY-IDLER Price: $15.72 |
| 27 |
322-6 |
SCREW-HH Price: $0.45 |
| 28 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 29 |
120-9500-03 |
BLADE-ATOMIC, 15.4 INCH Price: $21.88 |
