| Ref | Part Number | Description |
|---|
| 1 |
76-7010 |
RING-RETAINING Price: $3.66 |
| 2 |
105-3331 |
SEAL-SHAFT This part replaces 94-3008. Price: $35.63 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 4 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 5 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 6 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 7 |
94-3004 |
SHAFT-DRIVE, SPLINED Price: $564.48 |
| 8 |
94-3002 |
SCREW-CAP Price: $7.19 |
| 9 |
596501502 |
Keepers This part replaces 501832601. Price: $9.99 |
| 9 |
94-3005 |
BACKPLATE ASM Price: $1,185.62 |
| 10 |
76-6980 |
O-RING Price: $11.28 |
| 11 |
587241401 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH01 Price: $229.99 |
| 11 |
94-3009 |
PLUG Price: $34.97 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 15 |
599306202 |
TANK ASSY W/CAP REAR CARB This part replaces 532422901. Price: $249.99 |
| 16 |
94-3003 |
PLATE-VALVE Price: $515.64 |
| 17 |
76-6910 |
ROTATING KIT Price: $2,143.15 |
| 18 |
585124801 |
CAP ASSY FUEL 3" GRAY Price: $17.99 |
| 18 |
76-6970 |
INSERT-PLATE, CAM Price: $140.84 |
| 20 |
532424341 |
CONTROL.THROTTLE.PRO. Price: $34.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 85 |
501606901 |
BOLT.HEX.7/16-20X3.GR5.YELLOW Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
| 116 |
539132624 |
KNOB - SHIFT This part replaces 532424659. Price: $6.99 |
| 117 |
532420828 |
VALVE FUEL RESERVE Price: $27.99 |
| 138 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
