| Ref | Part Number | Description |
|---|
| 1 |
3220-3 |
NUT-HJ Price: $0.28 |
| 1 |
817541011 |
Screw, Tapping #10-24 x .668 Price: $9.47 |
| 2 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 2 |
532160672 |
GEAR CASE, UPPER Price: $8.99 |
| 3 |
323-9 |
SCREW-HH Price: $1.29 |
| 3 |
532057072 |
SEAL Price: $4.99 |
| 4 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 4 |
532183908 |
SHAFT.DRIVE.HI-VAC.EZ Price: $32.99 |
| 5 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 5 |
532160818 |
BEARING, NEEDLE, THRUST Price: $4.99 |
| 6 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 6 |
532077881 |
BEARING Price: $24.99 |
| 7 |
532160817 |
WASHER, THRUST Price: $3.99 |
| 7 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 8 |
532850848 |
HI PRO KEY Price: $4.99 |
| 8 |
75-3270-03 |
HUB-PIVOT, TRACTION This part replaces 75-3270. Price: $144.73 |
| 9 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 9 |
532184134 |
SHAFT.WORM.HI-VAC Price: $13.99 |
| 10 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 10 |
532160679 |
GEAR, HELICAL Price: $27.99 |
| 11 |
49-6440-03 |
PEDAL-FORWARD This part replaces 49-6440. Price: $84.90 |
| 11 |
532160676 |
KIT.GEARCASE.HALVES.RWGD.21" This part replaces 532160673. Price: $14.99 |
| 12 |
532057079 |
THRUST WASHER Price: $1.99 |
| 12 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 13 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 13 |
812000039 |
KLIP RING Price: $4.99 |
| 14 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW Price: $3.99 |
| 14 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 16 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 17 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 18 |
75-6710 |
DECAL - FAST/SLOW Price: $5.87 |
| 19 |
233-42 |
KNOB Price: $12.88 |
| 20 |
75-6490 |
LEVER ASM Price: $78.45 |
| 21 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 22 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 24 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 25 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 28 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 29 |
63-7733 |
LH BRAKE CABLE ASM Price: $210.39 |
| 30 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 31 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 32 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 33 |
75-1440-03 |
PEDAL-BRAKE, LH This part replaces 75-1440. Price: $207.74 |
| 34 |
256-42 |
BUSHING Price: $7.03 |
| 35 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 36 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 37 |
75-2170-03 |
TUBE-CONTROL, PUMP This part replaces 75-2170. Price: $103.73 |
| 38 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 39 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 40 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 41 |
32121-50 |
PIN-SPRING Price: $1.21 |
