| Ref | Part Number | Description |
|---|
| 1 |
120-4155 |
PANEL ASM Price: $321.47 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
108-7604 |
COVER-LH Price: $55.56 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 3 |
108-7605 |
COVER-RH Price: $55.56 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
32144-112 |
SCREW-HWH Price: $0.99 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
3250-22 |
SCREW-PPH Price: $4.09 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
115-8849-03 |
PLATE-COVER Price: $23.24 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
3234-21 |
SCREW-HHF Price: $2.19 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
112-7404 |
ANGLE-MOUNTING Price: $20.18 |
| 10 |
94-2413 |
NUT-U Price: $1.79 |
| 11 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 12 |
117-2380-03 |
PANEL-SWITCHES, CONTROL ARM Price: $128.16 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $22.99 |
| 13 |
3290-409 |
RIVET Price: $0.34 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
108-7602 |
REST-ARM Price: $158.43 |
| 15 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 16 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
121-5159 |
IGNITION SWITCH ASM Price: $84.21 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 21 |
120-6310 |
LCD DISPLAY ASM Price: $584.72 |
| 27 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 28 |
99-7420 |
PLUG-HOLE Price: $7.64 |
| 29 |
95-8999 |
SWITCH Price: $42.14 |
| 30 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 31 |
161-8355 |
CUP HOLDER ASM This part replaces 117-2378. Price: $12.36 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
107069 |
CLIP Price: $1.79 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 33 |
99-7411 |
POINT-POWER Price: $30.69 |
| 34 |
99-7416 |
CAP Price: $6.64 |
| 35 |
93-9999 |
SWITCH-PTO Price: $42.99 |
| 36 |
110-0542 |
SPACER-FLANGE Price: $4.94 |
| 37 |
100-1535 |
SWITCH Price: $84.91 |
| 38 |
32144-18 |
SCREW-HWH Price: $1.80 |
