| Ref | Part Number | Description |
|---|
| 1 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 1 |
521615501 |
CRANKCASE-C Price: $32.99 |
| 2 |
105-0950 |
PIVOT SHAFT ASM Price: $77.36 |
| 2 |
506689001 |
BOLT TORX This part replaces 506616201. Price: $3.99 |
| 3 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 3 |
504121201 |
GASKET CASE This part replaces 521615601. Price: $3.99 |
| 4 |
100-1270 |
SWITCH-PROXIMITY Price: $96.57 |
| 4 |
545120005 |
RING SNAP Price: $1.99 |
| 5 |
100-4872 |
PLATE-SWITCH, NEUTRAL Price: $11.84 |
| 5 |
505296701 |
SEAL Price: $6.99 |
| 6 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 7 |
140-2266 |
BRACKET-SENSOR This part replaces 108-6732. Price: $34.82 |
| 8 |
32128-10 |
NUT-LOCK, HHF Price: $0.27 |
| 9 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 10 |
105-1006-01 |
BRACKET-SWITCH Price: $31.54 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 12 |
3229-10 |
SCREW-CARR Price: $0.22 |
| 13 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 14 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 15 |
3290-495 |
PIN-KLIK Price: $5.47 |
| 16 |
3272-21 |
PIN-COTTER Price: $3.09 |
| 17 |
105-0983-01 |
BAR-PROP Price: $16.53 |
| 18 |
112-6516 |
H FRAME ASM Price: $844.66 |
| 19 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 20 |
92-5836 |
WASHER Price: $5.34 |
| 21 |
114-2702 |
LINK ASM Price: $203.46 |
