| Ref | Part Number | Description |
|---|
| 1 |
98-9567 |
COLLAR Price: $3.78 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 2 |
98-9369 |
CLIP-CIRCULAR, EXTERNAL Price: $0.70 |
| 3 |
98-9570 |
BEARING-MINIATURIZE Price: $13.60 |
| 4 |
98-9681 |
SPRING-GOVERNOR Price: $12.06 |
| 5 |
98-9645 |
SPRING-START Price: $11.13 |
| 6 |
107-9083 |
LEVER-THRUST This part replaces 98-9660. Price: $29.76 |
| 7 |
98-9692 |
ROLLER Price: $11.45 |
| 8 |
98-9568 |
COLLAR Price: $4.68 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 9 |
98-9571 |
BEARING-MINIATURIZE Price: $8.24 |
| 10 |
98-9593 |
WASHER-PLAIN Price: $2.33 |
| 11 |
98-9659 |
LEVER-FORK Price: $26.50 |
| 12 |
586729001 |
PULLEY.ENGINE This part replaces 532401985. Price: $27.99 |
| 12 |
98-9566 |
SHAFT-LEVER, FORK Price: $23.27 |
| 13 |
98-9682 |
GASKET Price: $0.95 |
| 14 |
130-8182 |
KIT-SHAFT COVER, FORK LEVER This part replaces 98-9569. Price: $13.53 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532407545. Price: $44.99 |
| 15 |
98-9351 |
BOLT Price: $0.98 |
| 16 |
99-8380 |
FORK LEVER ASM Price: $172.25 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 81 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 82 |
181654 |
Plug Drain Oil Price: Call Us |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
