| Ref | Part Number | Description |
|---|
| 000000000 |
| |
For 96795400300. Engine, Kawasaki FR730V 24 HP. For engine replacement parts, see a Kawasaki dealer. Price: Call Us 000000000 |
| 2 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 5 |
581886702 |
BRACKET MUFFLER MS431BLK Price: $19.99 |
| 6 |
583593901 |
ARM.IDLER This part replaces 532448145. Price: $11.99 |
| 7 |
582538902 |
SPINDLE.IDLER This part replaces 582538901. Price: $4.99 |
| 8 |
531350601 |
PULLEY IDLER, BACKSIDE 3 INCH This part replaces 539110311. Price: $19.99 |
| 9 |
587537401 |
PULLEY.ENGINE Price: $22.99 |
| 10 |
587660101 |
SPACER.SPACER.625 W/OGURA.LCC Price: $5.99 |
| 11 |
539132859 |
HEAT SHIELD Price: $22.99 |
| 12 |
587633302 |
CLUTCH.STOP.OGURA LCC.BLACK Price: $7.99 |
| 13 |
587451202 |
GUARD.MUFFLER.WO.TOW.HITCHX431 Price: $44.99 |
| 14 |
539131604 |
MUFFLER ASM TWIN Price: $39.99 |
| 15 |
547878302 |
SPRING BELT TENSIONER BLACK This part replaces 532196105. Price: $5.99 |
| 20 |
501603701 |
BEARING.FLANGED.PLASTIC.3/4ID Price: $5.99 |
| 21 |
582539502 |
Bolts This part replaces 582539501. Price: $5.99 |
| 22 |
596433901 |
Screws This part replaces 874520656. Price: $2.99 |
| 23 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 25 |
581332806 |
Bolts This part replaces 581332803. Price: $6.99 |
| 28 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 32 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 33 |
532126197 |
WASHER Price: $6.99 |
| 34 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
