| Ref | Part Number | Description |
|---|
| 1 |
131696 |
CONTROL BAR Price: Call Us |
| 2 |
131697X479 |
SUB= 154480X479 Price: Call Us |
| 3 |
134081X479 |
SUB= 151590X479 Price: Call Us |
| 4 |
132001 |
ROPE GUIDE Price: Call Us |
| 5 |
63601 |
SUB= 73800400 Price: Call Us |
| 6 |
131959 |
BOLT.HANDLE.LM Price: Call Us |
| 7 |
664-26 |
SUB= 7192J Price: Call Us |
| 8 |
85692 |
SUB= 74250434 Price: Call Us |
| 9 |
851462 |
CONTROL THROTTLE Price: Call Us |
| 10 |
85723 |
WASHER PM Price: Call Us |
| 12 |
750097 |
TAPPING SCREW Price: Call Us |
| 15 |
51793 |
HAIRPIN COTTER Price: Call Us |
| 16 |
133188X479 |
DISCHARGE GUARD Price: Call Us |
| 17 |
700063X479 |
REAR BAFFLE Price: Call Us |
| 18 |
86344 |
SCREW PM Price: Call Us |
| 19 |
700356X479 |
PLATE.BACK.20RD Price: Call Us |
| 20 |
700363X479 |
BAFFLE.SIDE Price: Call Us |
| 21 |
133259 |
SUB= 140657 Price: Call Us |
| 22 |
73510400 |
NUT Price: Call Us |
| 24 |
751592 |
LOCKNUT PM Price: Call Us |
| 25 |
700913X479 |
SUB= 150956 Price: Call Us |
| 26 |
700915X479 |
SUB= 150956 Price: Call Us |
| 27 |
55187 |
SCREW Price: Call Us |
| 29 |
700375 |
SUB= 700325X007 Price: Call Us |
| 30 |
84920 |
SUB= 146630 Price: Call Us |
| 32 |
700331X004 |
SPRING SELECTOR Price: Call Us |
| 33 |
87877 |
KNOB PM Price: Call Us |
| 34 |
85021X004 |
AXLE ARM Price: Call Us |
| 36 |
84921 |
SUB= 142748 Price: Call Us |
| 37 |
800390 |
SUB= 146247 Price: Call Us |
| 38 |
52160 |
WASHER Price: Call Us |
| 39 |
85179 |
RETAINER CLIP PM Price: Call Us |
| 40 |
77400 |
HUB CAP Price: Call Us |
| 41 |
88652 |
HINGE SCREW Price: Call Us |
| 43 |
54583 |
SCREW Price: Call Us |
| 45 |
850998 |
SCREW Price: Call Us |
| 46 |
107339X |
DECAL HYT Price: Call Us |
| 51 |
105-9329 |
GASKET-FUNNEL, AIR This part replaces 99-9182. Price: $67.17 |
| 51 |
132198X479 |
SUB= 144961 Price: Call Us |
| 52 |
701779 |
KIT.HSG.20RD Price: Call Us |
| 53 |
851084 |
SCREW Price: Call Us |
| 54 |
850263 |
LOCKWASHER Price: Call Us |
| 56 |
134871 |
SUB= 145106 Price: Call Us |
| 57 |
850977 |
BLADE ADAPTOR Price: Call Us |
| 65 |
83816 |
SCREW PM Price: Call Us |
| 66 |
213146 |
CABLE CLAMP Price: Call Us |
| 67 |
132655 |
GRASS BAG Price: Call Us |
| 68 |
133413 |
CATCHER FRAME Price: Call Us |
| 71 |
87930 |
GUIDE CLIP PM Price: Call Us |
| 72 |
128415 |
BLIND RIVET Price: Call Us |
| 73 |
133169X479 |
MULCHER PLATE Price: Call Us |
| 94 |
99-9224 |
VALVE-IDLE ADJ. Price: $34.96 |
| 98 |
99-9225 |
SCREW-IDLE SPEED Price: $10.43 |
| 104 |
99-9226 |
PIN-FLOAT HINGE Price: $9.60 |
| 105 |
99-9227 |
VALVE-NEEDLE Price: $53.84 |
| 113 |
99-9228 |
TUBE-JET Price: $38.19 |
| 117 |
99-9229 |
JET-MAIN Price: $60.43 |
| 117 |
99-9230 |
JET-MAIN (HIGH ALTITUDE) Price: $70.24 |
| 121 |
99-9231 |
CARBUERTOR KIT Price: $250.07 |
| 122 |
99-9184 |
SPACER-CARBURETOR Price: $68.15 |
| 125 |
99-9185 |
DISCONTINUED Price: Call Us |
| 131 |
99-9232 |
SHAFT-THROTTLE Price: $106.45 |
| 133 |
99-9233 |
FLOAT-CARBURETOR Price: $74.95 |
| 137 |
99-9234 |
GASKET-BOWL, FLOAT Price: $8.54 |
| 141 |
99-9235 |
SHAFT-CHOKE Price: $64.37 |
| 142 |
99-9236 |
NOZZLE-CARBURETOR Price: $67.26 |
| 151 |
99-9237 |
SCREW-CROSS / SLOTTED Price: $5.45 |
| 187 |
99-9238 |
LINE-FUEL Price: $23.90 |
| 240 |
108-3854 |
FILTER-FUEL This part replaces 99-9193. Price: $5.49 |
| 254 |
99-9239 |
DRAIN-CARBURETOR. BOWL Price: $16.82 |
| 355A |
99-9240 |
WASHER-SEAL Price: $10.99 |
| 387 |
99-9196 |
PUMP-FUEL Price: $291.24 |
| 601 |
99-9242 |
CLAMP-HOSE Price: $9.72 |
| 947 |
99-9243 |
SOLENOID-FUEL Price: $277.27 |
| 975 |
99-9244 |
BOWL-FLOAT Price: $57.63 |
| 1084A |
99-9199 |
CONNECTOR Price: $6.76 |
| 1084B |
99-9213 |
CONNECTOR Price: $7.44 |
| 1084C |
99-9245 |
CONNECTOR Price: $5.95 |
| 140753 |
MANUAL |
OP GEN PUS Price: Call Us 140753 |
