| Ref | Part Number | Description |
|---|
| 1 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 1 |
530037793 |
Foam- Air Filter Price: $1.99 |
| 2 |
530016101 |
Nut Price: $1.99 |
| 2 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 3 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 3 |
530035526 |
Grommet-Carb Adjust Price: Call Us |
| 4 |
530054144 |
Seal-Carb Adapter Price: $2.99 |
| 4 |
99-6970-03 |
SUPPORT-RADIATOR Price: $250.42 |
| 5 |
104-1418 |
STRIP-FOAM, RADIATOR Price: $23.57 |
| 5 |
530049700 |
Carb. Adapter Price: $3.99 |
| 6 |
530069247 |
Fuel Line Kit (Small) Price: $3.69 |
| 6 |
99-6936 |
RADIATOR Price: $1,331.21 |
| 7 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.69 |
| 7 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 8 |
530071579 |
CYLINDER This part replaces 530069606. Price: $29.99 |
| 8 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 9 |
109-0276 |
HOSE-FUEL This part replaces 104-0079. Price: $24.99 |
| 9 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 10 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 10 |
530016153 |
Screw Price: $1.99 |
| 11 |
530049227 |
Cylinder Shield Price: $8.99 |
| 11 |
99-6939 |
SHROUD-FAN Price: $256.71 |
| 12 |
3290-271 |
RIVET-POP Price: $0.25 |
| 12 |
530071835 |
Kit- Air Purge This part replaces 530047213. Price: $5.99 |
| 13 |
530015780 |
Screw Price: $1.99 |
| 13 |
98-9335 |
PLATE-WARNING, FAN Price: $6.17 |
| 14 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 14 |
530095646 |
Fuel Pick-up Ass’y. Price: $2.69 |
| 15 |
321-4 |
SCREW-HH Price: $0.99 |
| 15 |
530037652 |
Heat Insulator Price: $1.99 |
| 16 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 16 |
530052296 |
Assy. -Wire Harness Price: $4.99 |
| 17 |
104-0013 |
HOSE-RADIATOR, UPPER Price: $111.97 |
| 18 |
104-0014 |
HOSE-RADIATOR, LOWER Price: $68.34 |
| 18 |
530047442 |
Strap-Ground Price: $1.99 |
| 19 |
530039167 |
Module- Ignition Price: $31.99 |
| 19 |
66-3180 |
TUBE-VENT Price: $18.60 |
| 20 |
32128-20 |
NUT-HF Price: $0.99 |
| 20 |
530015814 |
Screw Price: $1.49 |
| 21 |
2412-103 |
CLAMP Price: $2.51 |
| 22 |
304-46 |
DRAINCOCK Price: $7.55 |
| 22 |
530016132 |
Screw Price: $1.99 |
| 23 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 23 |
530036103 |
Screen-Spark Price: Call Us |
| 24 |
530037813 |
Diffuser-Muffler Price: $1.99 |
| 25 |
117-3276 |
DECAL-DANGER This part replaces 93-7840. Price: $10.70 |
| 25 |
530069608 |
Gasket-Muffler (kit) Price: $5.99 |
| 26 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 26 |
530049870 |
Backplate-Muffler Price: $3.99 |
| 27 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 27 |
530047062 |
Assy. - Crankshaft Price: $72.99 |
| 28 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 28 |
99-6991 |
LH COOLER MOUNT ASM Price: $106.70 |
| 29 |
530056363 |
Assy.-Seal & Bearing Price: $11.99 |
| 29 |
99-6994 |
RH COOLER MOUNT ASM Price: $106.70 |
| 30 |
104-1448 |
HOOP-DRIVELINE Price: $23.07 |
| 31 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
530029805 |
Ring - Piston Price: $2.99 |
| 33 |
530069608 |
Gasket-Carb. Adap.(kit) Price: $5.99 |
| 34 |
530016187 |
Screw Price: $1.99 |
| 35 |
530016386 |
Screw Price: $5.99 |
| 36 |
530069608 |
Gasket - Carb. (kit) Price: $5.99 |
| 37 |
530069703 |
Kit-Carburetor (WT-324) Price: $37.25 |
| 38 |
530057480 |
Air Filter Housing This part replaces 530037804. Price: $4.99 |
| 39 |
530031163 |
Wrench - Bar Price: $4.99 |
