| Ref | Part Number | Description |
|---|
| 1 |
17720408 |
SCREW Price: Call Us |
| 1 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 2 |
132521 |
THROTTLE CONTROL Price: Call Us |
| 2 |
74-5790 |
SHAFT-PIVOT Price: $75.26 |
| 3 |
32121-123 |
PIN-ROLL Price: $0.81 |
| 4 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 4 |
71070512 |
SCREW Price: Call Us |
| 5 |
10040500 |
LOCKWASHER Price: Call Us |
| 5 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 6 |
125593X |
SUB= 272293 Price: Call Us |
| 6 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 7 |
3220-3 |
NUT-HJ Price: $0.28 |
| 7 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 8 |
121094X |
BOLT T Price: Call Us |
| 8 |
233-17 |
KNOB Price: $10.58 |
| 9 |
19101216 |
WASHER Price: Call Us |
| 9 |
72-0130 |
DISCONTINUED Price: Call Us |
| 10 |
10040400 |
LOCKWASHER Price: Call Us |
| 10 |
107-2561 |
NUT-HEX This part replaces 47-6990. Price: $14.65 |
| 11 |
68-8080 |
WHEEL-STEERING Price: $273.84 |
| 11 |
74780412 |
SUB= 74780414 Price: Call Us |
| 12 |
124097X |
MUFFLER Price: Call Us |
| 12 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 13 |
101326L |
DEFLECTOR.222573 Price: Call Us |
| 13 |
93-9415 |
PANEL-CONTROL, TOWER Price: $68.85 |
| 14 |
17030808 |
SUB= 17030814 Price: Call Us |
| 14 |
76-9450 |
DISCONTINUED Price: Call Us |
| 15 |
121851X |
SUB= 532137180 Price: Call Us |
| 15 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 16 |
323-8 |
SCREW-HH Price: $1.20 |
| 17 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 17 |
17490624 |
SCREW LT Price: Call Us |
| 18 |
95-1821 |
SPRING-COMPRESSION This part replaces 95-1821-03. Price: $6.71 |
| 19 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 20 |
69-1560-03 |
DISCONTINUED Price: Call Us |
| 20 |
73510600 |
NUT Price: Call Us |
| 21 |
2751R |
CLIP T Price: Call Us |
| 21 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 22 |
76-9050 |
ROD-BRAKE, PARK Price: $33.40 |
| 23 |
84-0680 |
LINK-SHIFT V Price: $32.00 |
| 24 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 25 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 26 |
63-7900-03 |
RACK Price: $144.55 |
| 27 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 28 |
20-9500 |
WASHER Price: $3.53 |
| 29 |
83-0740 |
DISC-FRICTION Price: $12.57 |
| 30 |
76-8340 |
SHAFT-PIVOT, STEERING Price: $89.60 |
| 31 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 32 |
76-8150-03 |
SUPPORT-SHAFT, STEERING Price: $25.87 |
| 33 |
92-9729 |
DISCONTINUED Price: Call Us |
| 34 |
340-138 |
FITTING-HYD, 45 DEG Price: $31.15 |
| 35 |
86-3210 |
DISCONTINUED Price: Call Us |
| 36 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 37 |
59-6430 |
DISCONTINUED Price: Call Us |
| 38 |
86-5570 |
HOSE ASM Price: $151.86 |
| 39 |
86-3220 |
HOSE ASM Price: $68.45 |
| 40 |
76-8140-03 |
BRACKET-GEAR, STEERING Price: $70.53 |
| 41 |
76-8160-03 |
SUPPORT-GEAR, STEERING Price: $25.24 |
| 42 |
323-6 |
SCREW-HH Price: $0.66 |
| 43 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 44 |
74-3670 |
DISCONTINUED Price: Call Us |
| 45 |
76-9100 |
SPACER Price: $4.07 |
| 46 |
82-4950 |
PLUNGER-SPRING Price: $145.10 |
| 47 |
74-5770-03 |
DISCONTINUED Price: Call Us |
| 48 |
104-7415 |
DISCONTINUED Price: Call Us |
| 49 |
21-9260 |
COVER-DUST Price: $8.19 |
| 50 |
340-70 |
NUT-LOCK Price: $2.10 |
| 51 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 52 |
2412-74 |
R-CLAMP Price: $2.37 |
| 53 |
340-159 |
FITTING-HYD, 90 DEG Price: $55.33 |
| 54 |
32144-57 |
SCREW Price: $1.04 |
| 55 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 56 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 57 |
94-8299 |
STEERING TUBE ASM Price: $135.28 |
| 58 |
86-5730 |
RH FRONT TUBE ASM Price: $85.91 |
| 59 |
86-5740 |
LH FRONT TUBE ASM Price: $126.12 |
| 60 |
2412-104 |
CLAMP-R Price: $2.37 |
| 61 |
2412-147 |
CLAMP-R Price: $2.51 |
| 62 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 63 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
