| Ref | Part Number | Description |
|---|
| 1 |
132-3777 |
STEERING CYLINDER ASM This part replaces 105-0411. Price: $781.15 |
| 2 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $45.99 |
| 3 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 4 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 5 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 6 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 7 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 8 |
84-5300 |
NUT-JAM Price: $9.99 |
| 9 |
107-2553 |
ROD END ASM Price: $150.07 |
| 9 |
532408667 |
KEEPER.BELT.ENGINE.4.25" Price: $8.99 |
| 10 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 11 |
532414737 |
KIT.SVC.CLTCH.OG.1.125" This part replaces 532179335. Price: $225.99 |
| 12 |
532194343 |
PULLEY ENGINE Price: $44.99 |
| 12 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 13 |
72-9710 |
HUB-TIRE Price: $288.21 |
| 14 |
5-3934 |
BOLT-CASTER Price: $55.92 |
| 15 |
115-3275 |
KIT-SERVICE, CASTOR FORK This part replaces 93-2529-01. Price: $530.51 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $90.99 |
| 17 |
3296-67 |
NUT-LOCK, NI Price: $5.05 |
| 18 |
3217-12 |
NUT-HEX Price: $3.12 |
| 18 |
532430218 |
CAP.ASM.FUEL.TANK.3"BLACK Price: $11.99 |
| 19 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 20 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN. Price: $19.99 |
| 21 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS THREAD Price: $2.99 |
| 23 |
325-6 |
SCREW-HH Price: $1.42 |
| 24 |
99-1485-01 |
PLATE-ADAPTER, MOTOR Price: $41.54 |
| 25 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 26 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 27 |
99-1486-01 |
PLATE-ADAPTER Price: $35.80 |
| 28 |
532008543 |
Line Fuel 54" This part replaces 532142158. Price: $7.99 |
| 29 |
532137180 |
ARRESTER SPARK (OPTIONAL) Price: $128.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
LOCKWASHER.7/16 This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532159955 |
EXHAUST TUBE LH *SUBS/2* Price: $25.99 |
| 71 |
532160589 |
EXHAUST TUBE RH Price: $39.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
