| Ref | Part Number | Description |
|---|
| 1 |
139-2651 |
CYLINDER, HYD This part replaces 105-3821. Price: $671.34 |
| 1 |
174619 |
Chassis Price: Call Us |
| 2 |
176554 |
Drawbar Price: Call Us |
| 2 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 3 |
17060612 |
Screw 3/8-16x3/4 Price: Call Us |
| 3 |
93-2255 |
HYD HOSE ASM Price: $52.69 |
| 4 |
93-2256 |
HYD HOSE ASM Price: $52.48 |
| 5 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 6 |
94-8198 |
PIN Price: $31.05 |
| 7 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 8 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 9 |
163976X428 |
Dash Price: Call Us |
| 9 |
283-68 |
PIN-CLEVIS Price: $11.26 |
| 10 |
72140608 |
Bolt 3/8-16 x 1 Price: Call Us |
| 11 |
167203 |
Panel Dash Lh Price: Call Us |
| 11 |
99-4115 |
FRONT LIFT FRAME ASM Price: $384.07 |
| 12 |
33096-00 |
WASHER-FLAT Price: $1.76 |
| 13 |
105-3838 |
SPACER Price: $10.45 |
| 13 |
178298 |
Panel Dash Rh Price: Call Us |
| 14 |
17490608 |
Screw Thdrol 3/8-16 x 1/2 Price: Call Us |
| 15 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 16 |
99-4201 |
TUBE-SPACER Price: $10.91 |
| 17 |
175260X428 |
Hood Price: Call Us |
| 17 |
99-4258 |
RH LINK BRACKET ASM Price: $51.12 |
| 18 |
99-4260 |
LH LINK BRACKET ASM Price: $51.12 |
| 19 |
105-3809 |
SPRING-TORSION, RH Price: $14.89 |
| 20 |
105-3818 |
SPRING-TORSION, LH Price: $14.89 |
| 20 |
162026 |
Plate Battery Price: Call Us |
| 21 |
99-4213 |
RH LIFT ARM ASM Price: $303.22 |
| 22 |
99-4212 |
LH LIFT ARM ASM Price: $303.22 |
| 23 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 24 |
93-2254 |
HYD HOSE ASM Price: $65.17 |
| 25 |
19131312 |
Washer 13/32 X 13/16 X 12 Ga Price: Call Us |
| 26 |
325-6 |
SCREW-HH Price: $1.42 |
| 26 |
73800600 |
Nut Lock Hex W/Ins 3/8-16 Unc Price: Call Us |
| 27 |
3218-5 |
NUT-JAM Price: $0.27 |
| 28 |
175289X428 |
Grille Price: Call Us |
| 28 |
93-2384 |
SPACER-CARRIER Price: $9.09 |
| 29 |
179761 |
Light Box Asm W/Lens Price: Call Us |
| 30 |
175692X428 |
Fender Price: Call Us |
| 31 |
139976 |
Bracket Fender Price: Call Us |
| 31 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 37 |
17490508 |
Screw Thdrol 6/16-18 x 1/2 TYT Price: Call Us |
| 38 |
175710 |
Bracket, Asm. Pivot Mower Rear Price: Call Us |
| 38 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 39 |
325-5 |
SCREW-HH Price: $1.20 |
| 40 |
325-14 |
SCREW-HH Price: $2.64 |
| 41 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 42 |
3250-17 |
SCREW-PPH Price: $1.76 |
| 43 |
99-4111-01 |
PLATE-TRANSPORT, 1 AND 3 Price: $49.03 |
| 44 |
99-4112-01 |
PLATE-TRANSPORT, 2 Price: $47.73 |
| 51 |
99-4225 |
PAD-WEAR Price: $10.18 |
| 54 |
161464 |
Screw Hex Wshd 8-18 x 7/8 Price: Call Us |
| 58 |
175351 |
Duct Hood Price: Call Us |
| 59 |
177579 |
Bushing Snap Price: Call Us |
| 60 |
72140606 |
Bolt Rd Hd Sqnk 3/8-16 Unc x 3/4 Price: Call Us |
| 64 |
174997 |
Dash Lower Price: Call Us |
| 74 |
73680600 |
Nut Crownlock 3/8-16 Unc Price: Call Us |
| 142 |
175702 |
Plate Reinforcement STLT Price: Call Us |
| 143 |
154966 |
Bracket Swaybar Chassis Price: Call Us |
| 144 |
175582 |
Bracket Footrest Price: Call Us |
| 145 |
156524 |
Rod Pivot Chassis/Hood Price: Call Us |
| 154 |
161897 |
Bracket Dash Rh Price: Call Us |
| 155 |
161900 |
Bracket Dash Lh Price: Call Us |
| 156 |
163805 |
Striker Plate Price: Call Us |
| 157 |
163806 |
Magnet Stealth Price: Call Us |
| 158 |
162037 |
Bracket Parking Brake Price: Call Us |
| 159 |
155123X428 |
Cupholder Price: Call Us |
| 161 |
164655 |
Extrusion Bumper Price: Call Us |
| 166 |
164863 |
Screw Hw Hd Hi-Lo #13-16 x 3/4 Price: Call Us |
| 206 |
170165 |
Bolt Shoulder 5/16-18 Price: Call Us |
| 209 |
17000612 |
Screw Hexwsh Thdrol 3/8-16 x 3/4 Price: Call Us |
| 213 |
169848X428 |
Skirt Grille Lh Price: Call Us |
