| Ref | Part Number | Description |
|---|
| 1 |
591359705 |
DECK.W/DECALS.60".7GA.ORG Price: $2,099.99 |
| 2 |
588264801 |
BELT 5V 176.00 Price: $99.99 |
| 3 |
539105711 |
BLADE - HEAVY DUTY 21" Price: $32.99 |
| 4 |
582462702 |
ARM.PNT.WLD.TENSIONR.IDLER.BLK Price: $37.99 |
| 5 |
539130646 |
PULLEY - 6.57 Price: $22.99 |
| 6 |
510015102 |
Pulleys This part replaces 510015101. Price: $49.99 |
| 7 |
582463003 |
COVER.PULLEY.LH.PNT Price: $49.99 |
| 8 |
582463004 |
COVER.PULLEY.RH.PNT Price: $49.99 |
| 9 |
582468801 |
CHUTE.DISCHARGE Price: $69.99 |
| 10 |
115-3018 |
NOZZLE HOLDER KIT Price: $440.14 |
| 10 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 12 |
574196402 |
Tubes This part replaces 574196401. Price: $5.99 |
| 13 |
574196502 |
Tubes This part replaces 574196501. Price: $17.99 |
| 14 |
539131518 |
BEARING, FLANGE Price: $9.99 |
| 15 |
510263701 |
BEARING, IDLER ARM Price: $5.99 |
| 16 |
582467302 |
BRACKET.CHUTE.ORG Price: $64.99 |
| 17 |
582463207 |
BRACKET PULLEY COVER MOUNT LH Price: $37.99 |
| 18 |
582463208 |
BRACKET PULLEY COVER MOUNT RH Price: $49.99 |
| 19 |
594913302 |
BELT.GUIDE.LOWER.PLATE.MS431 Price: $7.99 |
| 20 |
582470202 |
Keepers This part replaces 582470201. Price: $7.99 |
| 20 |
99-8301 |
NUT Price: $8.64 |
| 21 |
597783101 |
GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 22 |
590523702 |
PLATE.BACKING.DISCHARGE.CHT.BK Price: $19.99 |
| 23 |
582466402 |
Plates This part replaces 582466401. Price: $8.99 |
| 24 |
582468102 |
Shafts This part replaces 582468101. Price: $19.99 |
| 25 |
599502401 |
GSPW Spacers This part replaces 582468301. Price: $7.99 |
| 26 |
589455202 |
Spacers This part replaces 589455201. Price: $6.99 |
| 27 |
582468003 |
SPRING TORSION DECK IDLER Z500 This part replaces 582468001. Price: $22.99 |
| 28 |
510437502 |
BAFFLE, DIVERTER 54"/60" LH Price: $44.99 |
| 29 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 30 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539115620. Price: $2.99 |
| 30 |
99-8302 |
WASHER-ADJUSTING Price: $7.16 |
| 31 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 32 |
510022302 |
Screws This part replaces 510022301. Price: $5.99 |
| 33 |
872140628 |
BOLT.RDHD SQNK 3/8-16 X 3-1/2 Price: $3.99 |
| 34 |
594944501 |
Bolts This part replaces 872140864. Price: $7.99 |
| 35 |
596436901 |
Screws This part replaces 874490644. Price: $4.99 |
| 36 |
574210602 |
Screws This part replaces 574210601. Price: $2.99 |
| 37 |
525612802 |
Screws This part replaces 525612801. Price: $2.99 |
| 38 |
521996602 |
Screws This part replaces 521996601. Price: $4.99 |
| 39 |
582476402 |
Screws This part replaces 582476401. Price: $3.99 |
| 40 |
596433301 |
Bolts This part replaces 539130315. Price: $2.99 |
| 40 |
99-8303 |
SPRING-NOZZLE Price: $11.49 |
| 41 |
539119007 |
BLADE BOLT/WASHER Price: $8.99 |
| 42 |
574202002 |
Hardware This part replaces 574202001. Price: $4.99 |
| 43 |
539913847 |
NUT 3/8 PALNUT RTNG BLK PHOS Price: $3.99 |
| 44 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 45 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 46 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 47 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 48 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 49 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 50 |
596565001 |
Washers This part replaces 539109600. Price: $2.99 |
| 50 |
99-8304 |
SPACER-DISTANCE Price: $29.26 |
| 60 |
99-8305 |
ROD-PUSH Price: $60.67 |
| 70 |
99-8306 |
NUT-NOZZLE Price: $34.65 |
| 80 |
99-8307 |
WASHER-PLAIN Price: $8.84 |
| 90 |
115-3020 |
PIECE-NOZZLE Price: $150.73 |
| 100 |
99-8309 |
ADJUSTING WASHER ASM Price: $56.19 |
| 110 |
99-8310 |
WASHER-ADJUST (0.10MM) Price: $2.74 |
| 110 |
99-8311 |
WASHER-ADJUST (0.20MM) Price: $3.56 |
| 110 |
99-8312 |
WASHER-ADJUST (0.30MM) Price: $2.74 |
| 110 |
99-8313 |
WASHER-ADJUST (0.40MM) Price: $2.74 |
| 110 |
99-8314 |
WASHER-ADJUST (0.50MM) Price: $1.91 |
| 110 |
99-8315 |
WASHER-ADJUST (0.52MM) Price: $1.91 |
| 110 |
99-8316 |
WASHER-ADJUST (0.54MM) Price: $1.91 |
| 110 |
99-8317 |
WASHER-ADJUST (0.56MM) Price: $1.91 |
| 110 |
99-8318 |
WASHER-ADJUST (0.58MM) Price: $1.91 |
| 110 |
99-8319 |
WASHER-ADJUST (0.80MM) Price: $1.91 |
| 120 |
98-7676 |
GASKET Price: $2.73 |
