| Ref | Part Number | Description |
|---|
| 1 |
117-5135 |
RADIATOR This part replaces 99-3637. Price: $1,486.25 |
| 1 |
183334 |
Knob, Lever Price: Call Us |
| 2 |
112-1684 |
COOLER-OIL Price: $602.14 |
| 2 |
17501010 |
Screw #10-24 x 5/8 Price: Call Us |
| 3 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 3 |
178674 |
Control Assembly, Deflector Price: Call Us |
| 4 |
104-5429 |
CLAMP-FORM, WIRE Price: $11.80 |
| 4 |
73800600 |
Nut, Lock 3/8-16 Price: Call Us |
| 5 |
19131316 |
Washer, Flat 3/8 Price: Call Us |
| 5 |
325-17 |
SCREW-HH Price: $2.90 |
| 6 |
178659 |
Control Assembly, Chute Rotater Price: Call Us |
| 6 |
41-8440 |
WASHER Price: $1.49 |
| 7 |
178638X479 |
Support, Pivot Price: Call Us |
| 7 |
32128-49 |
NUT-HHF Price: $1.04 |
| 8 |
104-7201 |
NUT-HF Price: $0.69 |
| 8 |
150078 |
Screw, Hex Head 5/16-18 x 3/4 Price: Call Us |
| 9 |
183525 |
Spring, Deflector Price: Call Us |
| 9 |
321-4 |
SCREW-HH Price: $0.99 |
| 10 |
179829 |
Bolt, Shoulder Price: Call Us |
| 10 |
240-4 |
GROMMET-RUBBER Price: $9.91 |
| 11 |
110-8277-03 |
FRAME-RADIATOR Price: $233.96 |
| 11 |
155415 |
Washer, Flat Price: Call Us |
| 12 |
73800400 |
Nut, Lock 1/4-20 Price: Call Us |
| 12 |
99-8551 |
PLUG-PIPE Price: $4.79 |
| 13 |
105-7281 |
HOSE-AIR INLET, UPPER Price: $108.48 |
| 13 |
72250505 |
Bolt, Carriage 5/16-18 Price: Call Us |
| 14 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 14 |
73800500 |
Nut, Lock 5/16-18 Price: Call Us |
| 15 |
108-9930-0P |
BRACKET-BOTTLE This part replaces 108-9930-03. Price: $27.52 |
| 15 |
178628X428 |
Chute Assembly Price: Call Us |
| 16 |
108-0638 |
BOTTLE-OVERFLOW Price: $33.20 |
| 16 |
178633X428 |
Deflector Assembly Price: Call Us |
| 17 |
110-5542 |
HOSE-HYD Price: $119.39 |
| 17 |
179145 |
Seal, Deflector Price: Call Us |
| 18 |
128415 |
Rivet, Blind Price: Call Us |
| 18 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 19 |
183333 |
Knob, Speed Control Lever Price: Call Us |
| 19 |
323-10 |
SCREW-HH Price: $0.89 |
| 20 |
108-9935 |
STRIP-FOAM Price: $36.37 |
| 20 |
72270506 |
Bolt, Carriage 5/16-18 x 3/4 Price: Call Us |
| 21 |
33103-020 |
SCREW-HHF Price: $2.16 |
| 21 |
74041024 |
Screw #10-24 x 1-1/2 Price: Call Us |
| 22 |
110-5543 |
HOSE-HYD Price: $136.82 |
| 22 |
183292 |
Nut, Weld #10-24 Price: Call Us |
| 23 |
108-3284 |
HOSE-FUEL Price: $13.53 |
| 23 |
179156 |
Control Assembly, Power Steering Price: Call Us |
| 24 |
74780528 |
Screw, Hex Head 5/16-18 x 1-3/4 Price: Call Us |
| 25 |
155377 |
Nut, Lock 5/16-18 Price: Call Us |
| 25 |
2412-137 |
CLAMP-R, DOUBLE Price: $5.08 |
| 26 |
179257 |
Lever Assembly, Speed Control Price: Call Us |
| 26 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 27 |
108-9927 |
SHROUD-FAN Price: $123.47 |
| 27 |
169675 |
Retainer, Hairpin Price: Call Us |
| 28 |
108-2872 |
COLLAR-FAN This part replaces 104-4247. Price: $21.29 |
| 28 |
180445 |
Rod, Upper, Speed Control Price: Call Us |
| 29 |
107-2269 |
SEAL-BULB Price: $28.64 |
| 30 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 31 |
104-4246 |
FAN-ENGINE This part replaces 107-9096. Price: $154.04 |
| 32 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 34 |
105-7282 |
HOSE-RADIATOR, UPPER Price: $53.89 |
| 35 |
105-7283 |
HOSE-RADIATOR, LOWER Price: $34.82 |
| 36 |
109-0274 |
HOSE-FUEL Price: $12.99 |
| 37 |
106-6755 |
DECAL-CAP, RADIATOR Price: $18.49 |
| 38 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
