| Ref | Part Number | Description |
|---|
| 1 |
159944X428 |
Wheel Steering Price: Call Us |
| 1 |
66-6370 |
LIFT ARM ASM Price: $430.43 |
| 2 |
172393 |
Axle Asm Cast Iron LT Price: Call Us |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 9 |
66-7150 |
ARM-PUSH, RH Price: $536.26 |
| 10 |
175121 |
Link Drag Price: Call Us |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 12 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 13 |
136518 |
Spacer Brg. Axle Front Price: Call Us |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 14 |
46-8840-01 |
SPRING-LIFT ARM This part replaces 46-8840. Price: $35.71 |
| 15 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 15 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 16 |
256-126 |
BUSHING Price: $9.36 |
| 17 |
177876 |
Shaft Asm. Steering Price: Call Us |
| 17 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 18 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 19 |
324-4 |
SCREW-HH Price: $0.95 |
| 20 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 21 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 22 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 24 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 25 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 26 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 27 |
32128-42 |
NUT-HF Price: $0.98 |
| 28 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 29 |
17060612 |
Screw 3/8-16x.75 Price: Call Us |
| 29 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 30 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 31 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 32 |
171888 |
Rod Tie Price: Call Us |
| 32 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 33 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga. Price: Call Us |
| 33 |
86-8100-01 |
BALL JOINT ASM This part replaces 86-8100. Price: $137.53 |
| 34 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 35 |
73540500 |
Crownlock Nut 5/16-24 Price: Call Us |
| 36 |
155099 |
Bushing Strg Price: Call Us |
| 36 |
3-1365 |
CHAIN Price: $72.97 |
| 37 |
152927 |
Screw Price: Call Us |
| 37 |
68-3270 |
BUMPER-RUBBER This part replaces 67-9800. Price: $37.99 |
| 38 |
159946X428 |
Insert Cap Strg Wh Au Price: Call Us |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
19132411 |
Washer 13/32 X 2-3/8 X 12 Ga Price: Call Us |
| 39 |
5-2942 |
SHACKLE Price: $16.99 |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
159945 |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054X428 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 44 |
153720 |
Extension Steering Shaft LR/LT Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 51 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Price: Call Us |
| 54 |
74780520 |
Bolt Fin Hex 5/16-18 Unc x 1-1/4 Price: Call Us |
| 63 |
74780616 |
Bolt Fin Hex 3/8-16unc x 1 Gr. 5 Price: Call Us |
| 65 |
160367 |
Brace Axle Price: Call Us |
| 67 |
72140618 |
Bolt Rdhd Sq 3/8-16 Unc x 2-1/4 Price: Call Us |
| 68 |
169827 |
Axle, Brace Price: Call Us |
| 71 |
175146 |
Steering Asm. Price: Call Us |
| 82 |
169835 |
Bracket Susp. Chassis Front Price: Call Us |
| 87 |
173966 |
Washer Flat .781 x 1-1/2 x .14 Price: Call Us |
| 88 |
175118 |
Bolt Shoulder 7/16-20 Unc Price: Call Us |
