| Ref | Part Number | Description |
|---|
| 1 |
106-0050 |
LH INNER COVER ASM This part replaces 69-6800. Price: $186.64 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
69-6360-01 |
PLATE-GEARBOX, LH ASM This part replaces 69-6360. Price: $258.21 |
| 4 |
32128-21 |
NUT-HF Price: $0.39 |
| 5 |
237-81 |
O-RING Price: $2.76 |
| 6 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 7 |
237-65 |
O-RING Price: $2.50 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 8 |
88-9360 |
HOSE ASSY Price: $386.10 |
| 9 |
88-9370 |
HOSE ASSY Price: $240.46 |
| 10 |
237-22 |
O-RING Price: $2.43 |
| 11 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 12 |
237-42 |
O-RING Price: $2.78 |
| 13 |
94-4907 |
MOTOR-HYD This part replaces 69-2780. Price: $1,685.80 |
| 14 |
63-0660 |
GEARBOX PULLEY WA Price: $80.31 |
| 15 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 16 |
106-0051 |
LH OUTER COVER ASM This part replaces 69-6810. Price: $251.73 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
3269-25 |
RIVET-POP Price: $0.27 |
| 18 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 19 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 20 |
69-6260 |
MAGNET Price: $58.32 |
| 21 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
3233-30 |
SCREW-CARR Price: $3.26 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 24 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540. Price: $62.48 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
32128-23 |
NUT-HF Price: $1.51 |
| 25 |
532198893 |
CABLE.START.RED.17.5". Price: $11.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 28 |
95-0845 |
DECAL-HOC This part replaces 71-4260. Price: $11.75 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532401104 |
HARNESS.IGN.DASH.HUQ/P Price: $59.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 59 |
596941001 |
Outlets This part replaces 532400303. Price: $11.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 90 |
532400724 |
COVER.TERMINAL.BATTERY Price: $3.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 101 |
532198317 |
PIGTAIL.MATNLK.NEW.HAR Price: $6.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
