| Ref | Part Number | Description |
|---|
| 1 |
104-3796 |
FITTING-ELBOW 90 Price: $120.65 |
| 1 |
121006X |
Rod Asm., Lever Price: Call Us |
| 2 |
108-4008 |
COOLER-OIL This part replaces 99-5495. Price: $813.52 |
| 2 |
180045 |
Shaft Asm., Lift Vgt Price: Call Us |
| 3 |
159189 |
Lever Asm., Lift Rh Price: Call Us |
| 3 |
32128-49 |
NUT-HHF Price: $1.04 |
| 4 |
105-3994 |
BRACKET-RADIATOR Price: $333.75 |
| 4 |
12000022 |
E-Ring Truarc #5133-87 Price: Call Us |
| 5 |
104-2223 |
SEAL-BULB Price: $28.48 |
| 5 |
19292016 |
Washer 29/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 6 |
100-5550 |
HOSE-CLEANER, AIR Price: $176.60 |
| 6 |
71110624 |
Bolt, Fin Hex 3/8-16 x 1-1/2 Price: Call Us |
| 7 |
105-3934-03 |
BRACKET-SEAL, HOOD Price: $68.60 |
| 7 |
125631X |
Grip, Handle Price: Call Us |
| 8 |
124526X |
Button, Plunger Price: Call Us |
| 8 |
139-0972 |
RADIATOR This part replaces 99-5426. Price: $1,684.80 |
| 9 |
110-3258 |
HOSE-FUEL This part replaces 71-3370. Price: $23.35 |
| 9 |
122364X |
Plunger, Lever Lift Price: Call Us |
| 10 |
183894 |
Spring 0.62 OD x 2.125 Price: Call Us |
| 10 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 11 |
175375 |
Link Lift Price: Call Us |
| 11 |
93-5957 |
CAP-RADIATOR Price: $20.99 |
| 12 |
163552 |
Retainer, Spring Price: Call Us |
| 12 |
99-5428 |
SHROUD-RADIATOR Price: $420.87 |
| 13 |
2412-111 |
CLAMP Price: $4.39 |
| 14 |
100-5547 |
HOSE-RADIATOR Price: $74.35 |
| 15 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 16 |
100-5505-03 |
BRACKET-TANK Price: $32.07 |
| 17 |
99-2900 |
WASHER-FLAT Price: $1.49 |
| 18 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 19 |
120-5571 |
COOLANT RESERVOIR ASM This part replaces 104-2276. Price: $151.27 |
| 21 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 22 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 23 |
4939M |
Retainer, Spring Price: Call Us |
| 24 |
104-5426-03 |
COVER-BOTTOM Price: $35.07 |
| 24 |
73350800 |
Nut, Jam Hex 1/2-13 unc Price: Call Us |
| 25 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 26 |
73680800 |
Nut, Crownlock 1/2-13 unc Price: Call Us |
| 26 |
94-5780 |
SCREW-HWH Price: $7.49 |
| 27 |
93-6981 |
SPACER Price: $4.69 |
| 29 |
150233 |
Trunnion Inf. Height Price: Call Us |
| 30 |
104-5460-03 |
PLATE-MOUNT, OIL COOLER Price: $19.12 |
| 30 |
110807X |
Nut, Special Price: Call Us |
| 31 |
105-3943 |
CLAMP-COOLER, OIL Price: $8.70 |
| 31 |
19131016 |
Washer 13/32 x 5/8 x 16 Ga. Price: Call Us |
| 32 |
137150 |
Spring, Compression Inf Hgt Price: Call Us |
| 32 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 33 |
322-10 |
SCREW-HH Price: $0.70 |
| 33 |
76020308 |
Pin, Cotter 3/32 x 1/2 Price: Call Us |
| 34 |
104-5429 |
CLAMP-FORM, WIRE Price: $11.80 |
| 34 |
137167 |
Rod, Adj Lift Price: Call Us |
| 35 |
138057 |
Knob, Inf 3/8-16 unc Price: Call Us |
| 35 |
325-17 |
SCREW-HH Price: $2.90 |
| 36 |
41-8440 |
WASHER Price: $1.49 |
| 37 |
104-5428 |
BRACKET-OIL COOLER, TOP Price: $50.73 |
| 38 |
115-8155 |
DECAL-WARNING This part replaces 93-7275. Price: $5.90 |
| 38 |
155097 |
Pointer, Height Indicator Price: Call Us |
| 39 |
105-9233 |
SEAL-FOAM Price: $11.28 |
| 39 |
123935X |
Plug, Hole Price: Call Us |
| 40 |
105-9236 |
SEAL-FOAM Price: $2.67 |
| 40 |
17060516 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 41 |
105-9814 |
SEAL-BULB Price: $91.92 |
| 41 |
175994 |
Nut, Lift Link 7/16-20 Price: Call Us |
| 42 |
105-9858 |
SEAL-BULB Price: $31.67 |
| 42 |
19112410 |
Washer 11/32 x 1-1/2 x 10 Ga. Price: Call Us |
| 43 |
106-6755 |
DECAL-CAP, RADIATOR Price: $18.49 |
| 43 |
123934X |
Scale, Indicator Height Price: Call Us |
| 70 |
145212 |
Nut, Hexflange Lock Price: Call Us |
| 72 |
110452X |
Nut, Push Phos & Oil Price: Call Us |
| 73 |
73350600 |
Nut Hex Jam 3/8-16 unc Price: Call Us |
| 74 |
187277 |
Arm Susp. Rear RH Price: Call Us |
| 75 |
175805 |
Plate Asm Susp. Front Price: Call Us |
| 76 |
175560 |
Pin Flange Price: Call Us |
| 77 |
176205 |
Trunnion Susp. Arm Price: Call Us |
| 78 |
175689 |
Trunnion Susp. Front Price: Call Us |
| 79 |
187276 |
Arm Susp. Rear LH Price: Call Us |
| 85 |
189013 |
Insert Wear Price: Call Us |
