| Ref | Part Number | Description |
|---|
| 15 |
703E18264 |
FRONT MOUNTING PLATE SPACER Price: $34.81 |
| 16 |
703-21664 |
SEAT COVER PANEL (LH) Price: $22.78 |
| 17 |
703-21665 |
SEAT COVER PANEL (RH) Price: $25.06 |
| 18 |
703-21685 |
SEAT BOX COVER (FRONT) Price: $75.77 |
| 19 |
703-21704 |
SEAT BOX COVER (REAR) Price: $45.57 |
| 20 |
710-0134 |
CARRIAGE BOLT 1/4-20 x .62 Price: $3.71 |
| 21 |
710-0166A |
MACHINE SCREW 1/4-20:1 Price: $6.24 |
| 22 |
710-0276 |
CARRIAGE BOLT 5/16-18 x 1.00 Price: $3.68 |
| 23 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 24 |
710-05070A |
SCREW 1/4-20 x .5 Price: $6.01 |
| 25 |
710-0515 |
SCREW 1/2-20 x 3.50 GR5 Price: $10.13 |
| 26 |
710-05408 |
CARRIAGE BOLT 3/8-16 X1.25 GR5 Price: $3.37 |
| 27 |
710-06359A |
SCREW 3/8-16 x 1.25 GR5 Price: $4.13 |
| 28 |
710-1652 |
SCREW 1/4-20X.625 Price: $3.86 |
| 29 |
710-1807 |
SCREW 1/2-13 x 4.5 GR 5 Price: $10.13 |
| 30 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 31 |
710-3168 |
CARRIAGE BOLT 3/8-16 x 1.00 GR5 Price: $3.61 |
| 32 |
710-3251 |
SCREW 5/16-18X1.75 GR5 Price: $5.50 |
| 33 |
712-0229 |
PUSH NUT Price: $3.14 |
| 34 |
712-0239 |
HEX NUT Price: $5.01 |
| 35 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 36 |
712-04064 |
FLANGE LOCK NUT Price: $3.64 |
| 37 |
712-04065 |
NUT Price: $3.68 |
| 38 |
712-04150 |
NUT Price: $3.74 |
| 39 |
712-0421 |
WING NUT 5/16-18 Price: $5.99 |
| 40 |
712-04339 |
FLANGE NUT Price: $3.37 |
| 41 |
726-04072A |
RATCHET CLIP Price: $3.15 |
| 42 |
731-04591A |
CUP HOLDER Price: $13.84 |
| 43 |
735-05131 |
RADIAL BUMPER Price: $25.79 |
| 44 |
735-05147 |
BUMPER Price: $4.59 |
| 45 |
736-0159 |
FLAT WASHER Price: $3.71 |
| 46 |
736-04019 |
FLAT WASHER .531 x 1.25 x .181 Price: $7.02 |
| 47 |
736-3004 |
FLAT WASHER Price: $4.08 |
| 48 |
738-05171 |
SHOULDER SPACER Price: $6.19 |
