| Ref | Part Number | Description |
|---|
| 1 |
136-8483 |
FRAME-PULL, RH This part replaces 92-9177. Price: $382.66 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
3220-3 |
NUT-HJ Price: $0.28 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 4 |
147-3120 |
BALL JOINT RECEIVER ASM This part replaces 8-7710. Price: $16.35 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 8 |
62-2440 |
LIFT ARM ASM Price: $130.13 |
| 9 |
62-2420-01 |
BAR ASM-LIFT, CTR ARM This part replaces 62-2420. Price: $70.22 |
| 10 |
63-8750 |
PIN-PIVOT Price: $4.20 |
| 11 |
57-7650 |
SPRING-TORSION Price: $11.81 |
| 12 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 13 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 14 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 15 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 16 |
5-1226 |
WASHER Price: $3.90 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 18 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 19 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 20 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 21 |
322-1 |
SCREW-HH Price: $0.22 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
105-3822 |
HYD CYLINDER ASM This part replaces 83-2580. Price: $533.45 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 24 |
115-3259 |
KIT-SERVICE, PIN This part replaces 10-6110. Price: $39.21 |
| 25 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $7.99 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $17.99 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
3-1506 |
BUSHING Price: $2.42 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
138-6311 |
ARM-PULL-ASSEMBLY-LH This part replaces 92-0586. Price: $29.91 |
| 32 |
3290-317 |
WASHER-SPRING Price: $1.40 |
| 33 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 34 |
138-6303 |
ARM-PULL-ASSEMBLY-RH This part replaces 92-0585. Price: $29.91 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
133-2337 |
ROLLER ASM This part replaces 52-2720. Price: $176.14 |
| 36 |
21-8470 |
SHAFT-ROLLER Price: $62.10 |
| 37 |
133-2378 |
BEARING This part replaces 251-141. Price: $23.28 |
| 38 |
237-78 |
O-RING Price: $3.85 |
| 39 |
92-9767 |
HOSE This part replaces 63-3880. Price: $69.61 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $69.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $32.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
596039601 |
Bolts This part replaces 532192540. Price: $1.99 |
| 94 |
532191834 |
MODULE.REVERSE.ROS Price: $19.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
