| Ref | Part Number | Description |
|---|
| 1 |
132-5865 |
CANISTER-CARBON This part replaces 114-0289. Price: $80.55 |
| 1 |
532169831 |
CHASSIS STAMPING Price: $80.52 |
| 2 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 2 |
532176554 |
DRAWBAR, 12GA This part replaces 532169061. Price: $37.99 |
| 3 |
117-8399 |
STRAP-MOUNTING Price: $34.40 |
| 3 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
110-3254 |
HOSE-FUEL Price: $18.55 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 6 |
532155923 |
SADDLE FLAT Price: $11.99 |
| 6 |
68-3630 |
HOSE-FUEL Price: Call Us |
| 7 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 8 |
2412-80 |
CLAMP-HOSE Price: $4.39 |
| 8 |
532155138 |
CLIP RETAINER Price: $3.99 |
| 9 |
133-8499 |
VALVE-CHECK, VACUUM This part replaces 115-7868. Price: $14.10 |
| 9 |
532171796 |
DASH Price: $35.86 |
| 10 |
115-7871 |
HOSE-FUEL Price: $5.23 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
119-2965 |
STRAP-TANK Price: $32.35 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX This part replaces 532155927. Price: $9.99 |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 12 |
532145660 |
CLIP Price: $2.99 |
| 13 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 13 |
532173025 |
PANEL DASH RH Price: $9.92 |
| 14 |
120-5908 |
CABLE-BATTERY, NEGATIVE Price: $45.22 |
| 15 |
112-6808 |
CABLE-BATTERY, POSITIVE Price: $70.12 |
| 15 |
874180512 |
Screw, Machine, Truss Head 5/16-18 UNC x 3/4 Price: $3.99 |
| 16 |
106-5190 |
BATTERY Price: $170.85 |
| 16 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 17 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 17 |
532159639 |
HOOD.STEEL.LT.ORANGE This part replaces 532162237. Price: $64.99 |
| 18 |
93-7595 |
BATTERY BOX ASM Price: $83.58 |
| 19 |
109-1395 |
HOSE-FUEL Price: $15.64 |
| 20 |
115-9047 |
FUEL TANK ASM Price: $700.56 |
| 21 |
33114-016 |
SCREW-HH Price: $0.27 |
| 22 |
104-7102 |
PAD-BATTERY Price: $3.53 |
| 24 |
3339-175 |
STRAPPING-WEB This part replaces 94-1445. Price: $18.99 |
| 24 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 25 |
93-7968 |
PAD-FOAM Price: $33.52 |
| 26 |
119-6807 |
DECAL-WARNING Price: $7.37 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 28 |
532179100 |
GRILL ASSEMBLY This part replaces 532143499. Price: $169.99 |
| 29 |
532140273 |
LENS This part replaces 532168154. Price: $16.99 |
| 30 |
532169467 |
FENDER LT This part replaces 532177025. Price: $84.69 |
| 31 |
532136619 |
BRACKET FENDER Price: $4.99 |
| 33 |
532182507 |
FOOTREST.LH.BLACK This part replaces 532153539. Price: $37.99 |
| 34 |
532182508 |
FOOTREST.RH.BLACK This part replaces 532153538. Price: $22.99 |
| 35 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR This part replaces 532169834. Price: $9.99 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 52 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 53 |
532144697 |
BRACKET.GRILLE.LH Price: $4.99 |
| 54 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 Price: $3.99 |
| 55 |
532144696 |
BRACKET Price: $4.99 |
| 57 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 58 |
532150127 |
AIR DUCT P/L/LT Price: $13.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 206 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 212 |
532174503 |
INSERT, LENS This part replaces 532156229. Price: $22.99 |
