| Ref | Part Number | Description |
|---|
| 1 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX Price: $119.99 |
| 2 |
84-8500-01 |
LEVER-PTO This part replaces 84-8500. Price: $107.85 |
| 3 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 4 |
237-30 |
O-RING Price: $2.50 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
43-8610 |
GUIDE Price: $23.35 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
84-8520-01 |
BRACKET-SWITCH, PTO This part replaces 84-8520. Price: $11.07 |
| 7 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
43-3860 |
SHAFT-PIVOT, PTO Price: $55.10 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 12 |
106-4383 |
BELT-V, BANDED This part replaces 53-9660. Price: $40.02 |
| 13 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
3219-7 |
NUT-HEX Price: $1.53 |
| 16 |
587738903 |
KIT.SRVC.STEERINGSHAFT.3HISHFT This part replaces 532429374. Price: $44.99 |
| 17 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 18 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 19 |
3-8812 |
SPACER-SPRING, ANCHOR Price: $15.47 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 20 |
532441425 |
STEERING.BOOT.HUSQ.LT Price: $7.99 |
| 21 |
5-1747 |
SPRING-ADJUSTMENT Price: $5.76 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 22 |
92-5727 |
SCREW-LOCK, PATCH Price: $0.92 |
| 23 |
92-5723 |
BUSHING-FORK, PTO Price: $4.74 |
| 24 |
110-9681-03 |
FORK-PTO This part replaces 92-4060. Price: $195.34 |
| 25 |
27-7370 |
PTO BRAKE ASM Price: $218.20 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
93-3769 |
PIN-CLEVIS Price: $4.14 |
| 27 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 28 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 30 |
92-4058-01 |
ARM PTO This part replaces 92-4058. Price: $136.94 |
| 31 |
100-6599 |
PTO PIVOT ASM Price: $780.32 |
| 32 |
43-5550 |
SHAFT-ACTUATOR, PTO Price: $143.65 |
| 33 |
3219-3 |
NUT-HEX Price: $0.34 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 35 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
3256-41 |
WASHER Price: $1.18 |
| 37 |
5-0652 |
SPACER Price: $5.35 |
| 38 |
43-5570-01 |
ARM-ACTUATOR This part replaces 43-5570. Price: $164.96 |
| 39 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 40 |
251-252 |
BEARING Price: $98.35 |
| 41 |
251-234 |
COLLAR-LOCKING Price: $17.04 |
| 42 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 43 |
43-5540 |
SHAFT-PTO Price: $846.33 |
| 45 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 46 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 47 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 48 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 49 |
32121-9 |
PIN-ROLL, SLOTTED Price: $2.56 |
| 50 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 51 |
43-5630 |
YOKE-PTO Price: $80.75 |
| 52 |
5-0701 |
ANCHOR Price: $4.07 |
| 53 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
21-1600 |
CLAMP-LEVER, PTO Price: $279.65 |
| 55 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 56 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
237-7 |
O-RING Price: $8.82 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
218-461 |
NUT-HH Price: $2.50 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 71 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 72 |
321-4 |
SCREW-HH Price: $0.99 |
| 72 |
596039701 |
Bolts This part replaces 532428982. Price: $3.99 |
| 73 |
86-7050 |
BRACKET-SWITCH, ACTUATOR Price: $16.28 |
| 74 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 75 |
75-9890 |
WASHER-SHIM Price: $3.18 |
| 118 |
532406013 |
BUSHING, AXLE CAST Price: $4.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
