| Ref | Part Number | Description |
|---|
| 1 |
532132748 |
CONTROL.THROT.RH.BLK.FLG.44.75 Price: $20.99 |
| 1 |
95-7503 |
DIFFERENTIAL ASM Price: $2,433.39 |
| 2 |
106-1093 |
RING AND PINION SET Price: $954.77 |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 3 |
95-7502 |
CASE-DIFFERENTIAL Price: $331.35 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE This part replaces 532137978. Price: $39.99 |
| 4 |
99-7576 |
BOLT Price: $2.24 |
| 5 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 5 |
532144069 |
EXHAUST ASM. LEFT Price: $39.99 |
| 6 |
532144068 |
EXHAUST ASM. RIGHT Price: $22.99 |
| 6 |
99-7578 |
SHAFT-DIFFERENTIAL Price: $18.78 |
| 7 |
532138129 |
CLAMP Price: $3.99 |
| 7 |
99-7579 |
PINION-DIFFERENTIAL Price: $139.92 |
| 8 |
532122439 |
BRACKET MUFFLER Price: $6.27 |
| 8 |
99-7580 |
DISCONTINUED Price: Call Us |
| 9 |
596437001 |
Screws This part replaces 817190408. Price: $2.99 |
| 9 |
99-7581 |
GEAR-DIFFERENTIAL Price: $263.10 |
| 10 |
532145552 |
SHIELD HEAT LT Price: $5.99 |
| 10 |
99-7583 |
WASHER-DIFFERENTIAL This part replaces 99-7582. Price: $17.91 |
| 10 |
99-7584 |
WASHER-DIFFERENTIAL Price: $22.05 |
| 11 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 11 |
99-7588 |
PIN-SPRING Price: $0.75 |
| 12 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 12 |
99-7562 |
BEARING-BALL Price: $100.22 |
| 13 |
99-7585 |
SHIM 0.1 Price: $4.14 |
| 13 |
99-7586 |
SHIM 0.2 Price: $3.12 |
| 14 |
813280336 |
Nipple, Pipe 3/8 NPT x 4-1/2 Price: $2.42 |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 23 |
532128953 |
HEAT SHIELD Price: $3.08 |
| 24 |
817021008 |
SCREW Price: $3.99 |
| 25 |
532138672 |
CONTROL.CHOKE.51.00.BLK.W/BEND Price: $22.99 |
| 26 |
873610600 |
NUT Price: $2.99 |
| 27 |
817541008 |
SCREW Price: $3.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532151346 |
FUEL TANK 3.5G This part replaces 532141070. Price: $84.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
532106082 |
PAD-SPACER LT Price: $3.99 |
| 35 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 36 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532008543. Price: $14.99 |
| 39 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 40 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
