| Ref | Part Number | Description |
|---|
| 1 |
117-4760-01 |
SUPPORT-ROLLER Price: $306.77 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 3 |
87-3470 |
BUMPER Price: $18.89 |
| 4 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
105-3996-01 |
SUPPORT-ROLLER Price: $141.71 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
325-22 |
SCREW-HH Price: $4.26 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
325-20 |
SCREW-HH Price: $6.29 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
105-3970 |
SPRING-COMPRESSION Price: $46.60 |
| 10 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 11 |
105-9816 |
ROLLER-PLASTIC Price: $47.03 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $22.99 |
| 12 |
104-5545 |
SHAFT-ROLLER Price: $35.54 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $22.99 |
| 13 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
115-9137 |
SHROUD-PLATFORM Price: $443.77 |
| 15 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 15 |
532127218 |
FRONT LINK Price: $14.99 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 16 |
94-9024 |
LAMP ASM Price: $157.81 |
| 17 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 17 |
532175689 |
TRUNNION This part replaces 532130171. Price: $3.99 |
| 18 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 19 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
596917601 |
Pins This part replaces 876020308. Price: $1.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT This part replaces 532140302. Price: $5.99 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
