| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 1 |
63-7340 |
DISCONTINUED Price: Call Us |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
323-9 |
SCREW-HH Price: $1.29 |
| 4 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
94-7343 |
BASE-BATTERY This part replaces 66-2330. Price: $118.61 |
| 7 |
3272-15 |
PIN-COTTER Price: $0.47 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
63-7141 |
MOUNT-SHOCK, ENGINE Price: $61.74 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
321-4 |
SCREW-HH Price: $0.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 11 |
353-707 |
FITTING-HYD, 90 DEG Price: $43.04 |
| 12 |
63-7650 |
SEPARATOR-FILTER / WATER This part replaces 63-8280. Price: $155.85 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
63-8300 |
ELEMENT-SPIN ON Price: $28.79 |
| 14 |
323-18 |
SCREW-HH Price: $0.82 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
29-4730 |
WASHER-FLAT Price: $13.10 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
43-5320-03 |
PULLEY-PTO This part replaces 43-5320. Price: $373.80 |
| 18 |
63-6240 |
V-BELT Price: $54.64 |
| 19 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
139-7798-03 |
PTO SHAFT This part replaces 63-6220. Price: $527.02 |
| 21 |
3246-1 |
SCREW-SET Price: $6.24 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
251-253 |
BEARING Price: $22.84 |
| 24 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 26 |
92-8751-03 |
PTO BEARING BRACKET ASM This part replaces 63-6530. Price: $56.99 |
| 27 |
323-10 |
SCREW-HH Price: $0.89 |
| 28 |
54-9090 |
YOKE-END Price: $202.33 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
54-9170 |
TUBE-SLIP YOKE Price: $364.94 |
| 30 |
302-58 |
FITTING-STRAIGHT Price: $0.81 |
| 31 |
54-9050 |
SHAFT-SLIP YOKE Price: $200.01 |
| 32 |
54-9040 |
YOKE-END Price: $246.14 |
| 33 |
32151-34 |
RING-RETAINING Price: $0.67 |
| 34 |
322-9 |
SCREW-HH Price: $3.09 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
54-9180 |
U-JOINT KIT Price: $58.18 |
| 38 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 39 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 40 |
63-8310 |
VALVE-DRAIN Price: $13.54 |
| 41 |
323-11 |
SCREW-HH Price: $1.08 |
| 42 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 43 |
63-7140 |
MOUNT-SHOCK, ENGINE Price: $54.67 |
| 44 |
353-783 |
FITTING-STR Price: $29.05 |
| 45 |
63-8290 |
VENT-AIR Price: $19.94 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 46 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 53 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 54 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 55 |
71-3500 |
DISCONTINUED Price: Call Us |
| 56 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 57 |
66-2670 |
BRACKET-THROTTLE Price: $8.98 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 59 |
76-1000 |
THROTTLE CABLE Price: $35.96 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 60 |
92-5753 |
CLAMP-HOSE This part replaces 67-7210. Price: $2.10 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
43-4031 |
CABLE-BATTERY, POSITIVE Price: $136.18 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
28-1280 |
DISCONTINUED Price: Call Us |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 64 |
84-7580 |
PLATE-SUPPORT, BUSHING This part replaces 67-1640. Price: $74.62 |
| 65 |
32149-1 |
NUT-KEPS Price: $5.59 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
251-326 |
BEARING FLANGE Price: $29.84 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
67-1630 |
SPACER Price: $28.84 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 69 |
63-9750 |
MOUNT Price: $18.92 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 70 |
63-8410 |
WASHER Price: $1.76 |
| 72 |
32128-20 |
NUT-HF Price: $0.99 |
| 73 |
2412-104 |
CLAMP-R Price: $2.37 |
| 74 |
321-2 |
SCREW-HH Price: $2.79 |
| 75 |
3240-378 |
Cable Tie Price: Call Us |
