| Ref | Part Number | Description |
| 1 |
139-1035 |
SINGLE DRIVING SPINDLE ASM This part replaces 119-4547. Price: $986.94 |
| 1 |
530089069 |
Screw, Pan-WS + - Price: $3.33 |
| 1B |
30715 |
SHAFT & LEV Price: Call Us |
| 2 |
30357 |
SCREW Price: $2.62 |
| 2 |
323-6 |
SCREW-HH Price: $0.66 |
| 2 |
530089058 |
Cylinder Price: $3.33 |
| 3 |
30726 |
SHUTTER Price: Call Us |
| 3 |
530089059 |
Stud-Bolt Price: $3.33 |
| 3 |
92-5608-03 |
BLADE Price: $44.11 |
| 4 |
530089061 |
Gasket, Cylinder Price: $3.33 |
| 4 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 4B |
30951 |
SHAFT & LEV Price: Call Us |
| 5 |
530091516 |
Nut-Hex Price: $3.33 |
| 5 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 6 |
530089063 |
Washer-Plain-Small Price: $3.33 |
| 6 |
650399 |
SCREW This part replaces 630605. Price: $1.20 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 7 |
530089064 |
Lock Washer Price: $3.33 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 9 |
30950 |
CARB BODY Price: Call Us |
| 9 |
530089065 |
Screw, Pan Price: $3.33 |
| 10 |
30927 |
SHUTTER Price: Call Us |
| 10 |
530089066 |
Gasket Price: $3.33 |
| 11 |
30356 |
GASKET Price: $2.22 |
| 11 |
530089067 |
Nut Price: $3.33 |
| 12 |
27108 |
GASKET Price: Call Us |
| 12 |
530089068 |
Bolt-Upset-WSP Price: $3.33 |
| 13 |
29156 |
INLET NEEDLE Price: Call Us |
| 14 |
30354 |
FLOAT Price: Call Us |
| 14 |
530089072 |
Washer Price: $3.33 |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 15 |
530089071 |
Lock Washer Price: Call Us |
| 16 |
27136A |
DRAIN ASSY This part replaces 27136. Price: $5.96 |
| 16 |
530089073 |
Reed Valve Assembly Price: $3.33 |
| 17 |
32131 |
FLOAT BOWL This part replaces 30350. Price: $11.15 |
| 17 |
530089074 |
Reed Valve Block Price: $3.33 |
| 18 |
27136A |
DRAIN ASSY This part replaces 27137. Price: $5.96 |
| 18 |
530089075 |
Valve, Reed Price: $3.33 |
| 19 |
27136A |
DRAIN ASSY This part replaces 27138. Price: $5.96 |
| 19 |
530089076 |
Plate Price: Call Us |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 20 |
530091623 |
Lock Washer Price: $3.33 |
| 21 |
28945 |
POWER SCREW Price: $18.86 |
| 21 |
530089077 |
Screw, Pan Price: $3.33 |
| 22 |
530089079 |
Gasket Price: $3.33 |
| 22 |
630786 |
SPRING Price: $1.25 |
| 23 |
30355 |
NOZZLE Price: Call Us |
| 23 |
530089081 |
Piston Price: $3.33 |
| 24 |
27113 |
SPRING Price: $2.62 |
| 24 |
530089082 |
Piston Ring Set Price: $3.33 |
| 25 |
27554 |
GASKET Price: $1.05 |
| 25 |
530089083 |
Pin, Piston Price: $3.33 |
| 26 |
530089084 |
Ring, Snap Price: $3.33 |
| 27 |
530089085 |
Shim Price: $3.33 |
| 27 |
530089086 |
Shim Price: Call Us |
| 27 |
530089087 |
Shim Price: $3.33 |
| 27 |
530089088 |
Shim Price: $3.33 |
| 27 |
650506 |
SCREW This part replaces 630606. Price: $0.87 |
| 28 |
30815 |
BAFFLE Price: Call Us |
| 28 |
530089089 |
Key Price: $3.33 |
| 29 |
30817 |
SCREW Price: Call Us |
| 29 |
530089091 |
Crankcase Assembly Price: Call Us |
| 30 |
31390 |
REPAIR KIT Price: Call Us |
| 30 |
530089092 |
Stud Price: $3.33 |
| 31 |
530089093 |
Stud Price: $3.33 |
| 32 |
530089094 |
Pin, Dowel Price: Call Us |
| 33 |
530089095 |
Gasket Price: $3.33 |
| 34 |
530089096 |
Screw, Pan-WSP + - Price: $3.33 |
| 35 |
530089097 |
Screw Price: $3.33 |
| 36 |
530089098 |
Screw, Pan Price: $3.33 |
| 37 |
530089099 |
Gasket Price: Call Us |
| 38 |
530089101 |
Gasket Price: $3.33 |
| 39 |
530089102 |
Bearing, Ball Price: $3.33 |
| 40 |
530089103 |
Bearing, Ball Price: $3.33 |
| 41 |
530089104 |
Seal, Oil Price: $3.33 |
| 42 |
530089105 |
Seal, Oil Price: $3.33 |
| 43 |
530089106 |
Gasket Price: $3.33 |
| 44 |
530091516 |
Nut Price: $3.33 |
| 47 |
530089107 |
Screw, Pan-WS + - Price: Call Us |
| 48 |
530089108 |
Screw, Pan-WS + - Lock & Plain Price: Call Us |
| 49 |
530089109 |
Washer Price: $3.33 |
| 50 |
530089111 |
Nut Price: $3.33 |
| 51 |
530089112 |
Washer Price: Call Us |
| 52 |
530089113 |
Lock Washer Price: Call Us |
| 53 |
530089114 |
Grommet Price: $3.33 |
| 54 |
530089115 |
Plug, Spark Price: $3.33 |
| 55 |
530089116 |
Cap, Plug Price: $3.33 |
| 56 |
530089117 |
Spring, Cap Price: Call Us |
| 58 |
530089118 |
Crankshaft Assembly Price: Call Us |
| 59 |
530093024 |
Bearing Price: $3.33 |
| 60 |
530089121 |
Muffler Assembly Price: $3.33 |
| 61 |
530089122 |
Cover, Cylinder Price: $3.33 |
| 62 |
530093025 |
Recoil Starter Assembly Price: $3.33 |
| 63 |
530089123 |
Screw, Pan-WS + - Price: $3.33 |
| 64 |
530089124 |
Carburetor Assembly Price: $3.33 |
| 67 |
530089149 |
Breaker Price: $3.33 |
| 68 |
530089151 |
Felt, Cam Price: $3.33 |
| 69 |
530089148 |
Condenser Price: $3.33 |
| 70 |
530089147 |
Rotor Price: $3.33 |
| 71 |
530089146 |
Coil, Ignition Price: $3.33 |
| 72 |
530089155 |
Cap, Air Cleaner Price: $3.33 |
| 73 |
530089156 |
Net (1) Price: $3.33 |
| 74 |
530089153 |
Element Price: $3.33 |
| 75 |
530089158 |
Screw - Pan-WS-Lock & Plain Washer Price: $3.33 |
| 76 |
530089157 |
Net (2) Price: $3.33 |
| 77 |
530089152 |
Case, Air Cleaner Price: $3.33 |
| 78 |
530089154 |
Plate Price: $3.33 |
| 79 |
530089172 |
Pulley Price: $3.33 |
| 80 |
530089165 |
Screw Price: $3.33 |
| 81 |
530089171 |
Nut Price: $3.33 |
| 82 |
530089164 |
Ratchet Spring Price: $3.33 |
| 83 |
530089162 |
Spring, Return Price: $3.33 |
| 84 |
530089161 |
Reel Price: $3.33 |
| 85 |
530089159 |
Spring, Spiral Price: $3.33 |
| 87 |
530089166 |
Guide, Rope Price: $3.33 |
| 88 |
530089168 |
Handle Price: $3.33 |
| 89 |
530089173 |
Washer Price: $3.33 |
| 90 |
530089163 |
Ratchet Price: $3.33 |
