| Ref | Part Number | Description |
|---|
| 2 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 4 |
532427071 |
PULLEY.IMPELLER.SNOW This part replaces 532191079. Price: $27.99 |
| 4 |
67-8820-01 |
RH HINGE ASM This part replaces 67-8820. Price: $26.10 |
| 5 |
43-3900-03 |
FAN BELT GUARD ASM This part replaces 43-3900. Price: $290.98 |
| 5 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 6 |
596039201 |
GSPW Hardware This part replaces 532198541. Price: $2.99 |
| 7 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 8 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872270505. Price: $2.99 |
| 9 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 9 |
532199879 |
BOLT.HEX Price: $6.99 |
| 10 |
581708369 |
KIT.AUGER.HOUSING.404930X668 This part replaces 532407644. Price: $279.99 |
| 10 |
67-8810-01 |
LH HINGE ASM This part replaces 67-8810. Price: $26.95 |
| 11 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 11 |
532435830 |
BAR.SCRAPER.30.BLACK This part replaces 532407695. Price: $17.99 |
| 12 |
597433002 |
Brackets This part replaces 532184095. Price: $3.99 |
| 12 |
67-8190-01 |
BRACKET-SUPPORT, ENGINE This part replaces 67-8190. Price: $50.66 |
| 13 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 13 |
585056901 |
CHUTE.DISCHARGE.BASE This part replaces 532175322. Price: $9.99 |
| 14 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 14 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 15 |
532198552 |
WASHER, LOCK 5/16 Price: $6.99 |
| 16 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 16 |
874950512 |
Screw, Hex Head 5/16-18 x 3/4 Price: $3.99 |
| 18 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 18 |
532179582 |
SCREW, HEX HD 5/16X1 Price: $3.99 |
| 19 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 20 |
596039201 |
GSPW Hardware This part replaces 532198541. Price: $2.99 |
| 20 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 21 |
322-2 |
SCREW-HH Price: $0.69 |
| 22 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 22 |
532436125 |
PLATE.SKID.ADJ.RH.BLACK This part replaces 532184094. Price: $6.99 |
| 23 |
237-30 |
O-RING Price: $2.50 |
| 24 |
43-8610 |
GUIDE Price: $23.35 |
| 25 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 25 |
532198648 |
BOLT, HEX HEAD Price: $3.99 |
| 26 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 26 |
532420478 |
BEARING.AUGER.SHAFT This part replaces 532174658. Price: $7.99 |
| 27 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 28 |
237-7 |
O-RING Price: $8.82 |
| 28 |
588077502 |
BOLT SHEAR HX HD 1/4-20 CLEAR This part replaces 532198636. Price: $1.00 |
| 29 |
218-461 |
NUT-HH Price: $2.50 |
| 29 |
532174762 |
PLATE.SKID.ADJUSTABLE.LH.BLACK This part replaces 532184093. Price: $7.99 |
| 30 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 30 |
547572001 |
AUGER KIT 30" RH 420498X498 This part replaces 532407647. Price: $149.99 |
| 31 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 31 |
547571901 |
AUGER KIT 30" LH 420497X498 This part replaces 532407646. Price: $149.99 |
| 32 |
532407768 |
O-RING Price: $3.99 |
| 32 |
86-7040 |
ROD-PROP, SEAT Price: $29.51 |
| 33 |
532407769 |
BUSHING, FLANGE 3/4 Price: $7.99 |
| 34 |
532174681 |
WASHER, THRUST 3/4 Price: $11.99 |
| 35 |
532174684 |
BEARING TRUST 3/4 NTA-1220 Price: $6.99 |
| 36 |
532407757 |
SHAFT, IMPELLER Price: $89.99 |
| 37 |
532174683 |
WASHER, THRUST 5/8 Price: $6.99 |
| 38 |
532174686 |
BUSHING.FLANGE.(.625X.75) This part replaces 532407758. Price: $22.99 |
| 39 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $4.99 |
| 40 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW This part replaces 532407760. Price: $3.99 |
| 41 |
532174688 |
HOUSING.GEARBOX.RH.SNOW This part replaces 532407761. Price: $22.99 |
| 42 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $4.99 |
| 43 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $29.99 |
| 44 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 45 |
598831601 |
Service Kit This part replaces 532407763. Price: $199.99 |
| 46 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $59.99 |
| 47 |
532407765 |
HOUSING.GEARBOX.LH(SERVICE) Price: $22.99 |
| 48 |
531167901 |
SERVICE KIT IMPELLER WELDMENT This part replaces 532184105. Price: $44.99 |
| 49 |
596322101 |
BOLT HEXAGON BOLT 1/4-20 X 1-5 This part replaces 874780426. Price: $2.99 |
| 50 |
532175311 |
GASKET.AUGER.GEARBOX This part replaces 532407766. Price: $7.99 |
| 55 |
532198638 |
SPACER.3943.SLEEVE.250X.47 Price: $5.99 |
| 56 |
532429112 |
WRENCH.SNOWTHROWER.ZINC.YZ This part replaces 532180684. Price: $3.99 |
