Carburetor Parts (EPA)

Carburetor Parts (EPA)

Parts (83)

RefPart NumberDescription
1 33114-016 SCREW-HH This part replaces 48-7700. Price: $0.27
2 3253-4 WASHER-LOCK This part replaces 48-9570. Price: $0.25
3 53-6070 LEVER-BRAKE Price: $361.17
4 59-7240 CONTROL-THROTTLE Price: $74.01
5 3217-5 NUT-HEX Price: $0.25
6 3253-3 WASHER-LOCK Price: $0.31
7 3256-22 WASHER-FLAT Price: $0.39
8 25-8640 SCREW-HH Price: $1.09
9 25-9090 SWIVEL Price: $45.44
10 3296-13 NUT-LOCK, NI Price: $0.34
12 2412-31 CLAMP-BODEN Price: $1.56
13 92-9222 CABLE-HANDBRAKE Price: $220.53
14 323-4 SCREW-HH Price: $1.02
15 233-25 KNOB-CONTROL Price: $4.48
16 3217-6 NUT-HEX Price: $1.19
17 58-2170-03 BAR-LINKAGE, BRAKE This part replaces 58-2170. Price: $151.21
18 3256-3 WASHER-FLAT Price: $0.49
19 33094-00 WASHER-PLAIN This part replaces 48-8030. Price: $0.25
21 86-6100 SWITCH-INDICATOR, ELECTRICAL Price: $121.96
22 86-6090 HYD OIL FILTER ASM Price: $584.05
23 60-2140 SPRING Price: $26.64
24 92-9225 YOKE Price: $73.83
25 237-101 O-RING This part replaces 237-123. Price: $2.80
26 340-80 FITTING-STR Price: $47.82
27 340-65 O-RING Price: $3.58
28 92-9221 CABLE ASM Price: $19.69
29 322-6 SCREW-HH Price: $0.45
30 107-1818 DECAL-PANEL, SIDE CONTROL This part replaces 93-9402. Price: $84.40
30 58-6560 SIDE CONT. PANEL FACE Price: $57.25
31 340-64 O-RING Price: $4.22
32 84-6470-03 BRACKET-FILTER This part replaces 84-6470. Price: $56.96
33 340-10 Adapter (Incl. Ref. #25 31) Price: $45.09
34 48-7880 NUT-HEX Price: $0.25
35 43-5920 WASHER-LOCK, SPRING This part replaces 48-8000. Price: $0.25
36 52-6430 WASHER Price: $0.25
37 3253-5 WASHER-LOCK Price: $0.29
38 3290-378 TIE-CABLE Price: $0.79
39 3256-23 WASHER-PLAIN Price: $0.28
41 3217-6 NUT-HEX Price: $1.19
43 92-4754 DISCONTINUED Price: Call Us
44 321-4 SCREW-HH Price: $0.99
45 11-9030 SCREW-SHOULDER Price: $5.63
501466901 501466901 SCREW Price: $7.99
501468401 501468401 SPRING Price: $6.99
501468501 501468501 BALL Price: $6.99
501468701 501468701 SCREW Price: $6.99
501666101 501666101 FUEL INLET SCREEN Price: $12.99
501666901 501666901 GASKET, PUMP SIDE Price: $14.99
501667701 501667701 SPRING Price: $7.99
501667801 530035121 IDLE SCREW SPRING This part replaces 501667801. Price: $2.99
501668301 501668301 LEVER Price: $14.99
502254701 502254701 PUMP DIAPHRAGM Price: $19.99
503108701 503584601 SCREW This part replaces 503108701. Price: $2.99
503281805 536033701 CARBRETOR HD-12C H372 This part replaces 503281805. Price: $99.99
503563401 503563401 INLET NEEDLE Price: $14.99
503574201 503574201 WELCH PLUG Price: $6.99
503647801 503647801 GASKET SET Price: $14.99
503799601 503799601 LEVER Price: $3.99
503799801 503799801 COVER Price: $5.99
503799901 503799901 SHAFT Price: $11.99
503800001 503800001 THROTTLE FLAP Price: $4.99
503800701 503800701 GASKET Price: $64.99
503800801 503800801 SCREW Price: $19.99
503800901 503800901 SPRING Price: $8.99
503801401 503801401 TUBE Price: $3.99
503801501 503801501 BUSHING Price: $11.99
503855801 503855801 CHOKE FLAP Price: $3.99
503855901 503855901 RP NIPPLE Price: $17.99
503913901 503913901 LIMITER CAP Price: $2.99
503914001 503914001 LIMITER CAP Price: $4.99
503915401 503915401 CAP Price: $7.99
503943601 503943601 JET Price: $4.99
503943701 503943701 SPRING Price: $0.56
503943801 503943801 ADJUSTING SCREW Price: $5.99
503943901 503943901 IDLE SCREW Price: $7.99
504130905 504130905 GASKET Price: $2.99
505316717 505316717 SCREW Price: $6.99
505520125 505520125 FULCRUM PIN Price: $6.99
530035015 530035015 SCREW SHUTTERS Price: $2.99
537003301 537003301 JET Price: $5.99
537018901 537018901 LEVER Price: $3.99
537019001 537019001 SPRING Price: $8.99
537019101 537019101 CHOKE SHAFT Price: $14.99
