| Ref | Part Number | Description |
|---|
| 1 |
618-3189 |
PTO CLUTCH ASSEMBLY Not Available Price: |
| 2 |
919-3076B |
REAR COVER PLATE Not Available This part replaces 619-3076A. Price: |
| 2 |
99-1812 |
PLUG-DRAIN Price: $16.59 |
| 3 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 3 |
99-1813 |
GASKET Price: $29.00 |
| 4 |
710-1238A |
SCREW 5/16-18 x .875 GR5 HXFLG HD This part replaces 710-1238. Price: $3.74 |
| 4 |
99-1806 |
BOLT-HEAD, CYLINDER Price: $27.35 |
| 5 |
710-3006 |
SCREW .375 x 5/16-18 Not Available Price: |
| 5 |
99-1801 |
CAP - SEALING (DIA 20) Price: $13.58 |
| 6 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .5 GR5 Price: $4.02 |
| 6 |
99-1802 |
CAP - SEALING (DIA 25) Price: $15.04 |
| 7 |
710-3118 |
Screw, Hex Cap Lock, 3/8-16 x 1.0 GR5 Price: $4.77 |
| 7 |
99-1803 |
GUIDE-VALVE Price: $29.07 |
| 8 |
710-04003A |
SCREW 6MM x 40MM Not Available This part replaces 710-04003. Price: |
| 8 |
99-1811 |
BOLT W/WASHER Price: $2.70 |
| 9 |
711-1325 |
PTO SHAFT Not Available Price: |
| 9 |
99-1808 |
EYE-LIFTING, HEAD REAR Price: $23.69 |
| 10 |
911-1337A |
INPUT CLUTCH SHAFT Not Available This part replaces 711-1337. Price: |
| 10 |
99-1809 |
GASKET-HEAD, REAR Price: $5.59 |
| 11 |
711-1345 |
SHAFT-2000 PTO Not Available Price: |
| 11 |
99-1807 |
GASKET-HEAD, CYLINDER Price: $198.98 |
| 12 |
711-1371 |
PTO BACK SHAFT Not Available Price: |
| 12 |
99-1804 |
SEAT-VALVE, IN Price: $82.43 |
| 13 |
711-1373 |
PTO ACTUATOR SHAFT Not Available Price: |
| 13 |
99-1805 |
SEAT-VALVE, EX Price: $58.11 |
| 14 |
716-0180 |
Ring, Retaining Price: $10.38 |
| 15 |
716-0200 |
RETAINING RING Not Available Price: |
| 16 |
716-0201 |
RETAINING RING Not Available Price: |
| 17 |
716-0384 |
Ring, Retaining Price: $3.74 |
| 18 |
716-0393 |
RETAINING RING Not Available Price: |
| 19 |
716-0397 |
RETAINING RING Not Available Price: |
| 20 |
716-3001 |
Ring, Retaining Price: $3.96 |
| 21 |
717-3469 |
GEAR 81T Not Available Price: |
| 22 |
917-3479A |
AUX DRIVE GEAR 28T Not Available This part replaces 717-3479. Price: |
| 23 |
717-3487 |
PTO GEAR 61T Not Available Price: |
| 24 |
917-3490A |
AUX DRIVE PINION 28T Not Available This part replaces 717-3490. Price: |
| 25 |
917-3491A |
AUX DRIVE GEAR 32T Not Available This part replaces 717-3491. Price: |
| 26 |
717-3492 |
PTO GEAR 14T Not Available Price: |
| 27 |
717-3494B |
Gear, 2000 PTO Pinion: 54T Price: Call Us |
| 28 |
717-3500 |
PTO GEAR 34T Not Available Price: |
| 29 |
718-0668 |
SPLINE GEAR COUPLING Not Available Price: |
| 30 |
718-0681 |
PTO COVER Not Available Price: |
| 31 |
718-3116 |
Collar, 2 Speed Price: $77.88 |
| 32 |
718-3134 |
PTO COUPLING Not Available Price: |
| 33 |
919-0551A |
PTO ACTUATOR Not Available This part replaces 719-0551A. Price: |
| 34 |
721-0496 |
Seal, Oil Price: $9.52 |
| 35 |
721-0497 |
OIL SEAL Price: $12.92 |
| 36 |
721-0500 |
O-RING Not Available Price: |
| 37 |
721-0504 |
OIL PLUG Not Available Price: |
| 38 |
721-0509 |
OIL SEAL Not Available Price: |
| 39 |
921-3020A |
Seal, Oil, 1.18 ID This part replaces 721-3020A. Price: $10.75 |
| 40 |
732-0187 |
COMPRESSION SPRING Not Available Price: |
| 41 |
932-05125 |
DETENT SHAFT SPRING This part replaces 732-0863. Price: $3.66 |
| 42 |
732-0980 |
COMPRESSION SPRING Not Available Price: |
| 43 |
736-0355 |
Washer, Flat, .56 x 1.0 x .040 Not Available Price: |
| 44 |
736-0463 |
Washer, Flat, .25 x .630 x .0515 Price: $3.91 |
| 45 |
736-0615 |
Washer, Thrust, 1.007 x 1.542 x .03 Price: $8.02 |
| 46 |
741-0724 |
SLEEVE BEARING Not Available Price: |
| 47 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 48 |
741-0991 |
SLEEVE BEARING Not Available Price: |
| 49 |
741-1100 |
Bearing, Ball Price: $33.54 |
| 50 |
741-1118 |
NEEDLE BEARING Not Available Price: |
| 51 |
941-3033A |
Bearing, Ball This part replaces 741-3033A. Price: $50.07 |
| 52 |
941-3037 |
Bearing, Ball This part replaces 741-3037. Price: $38.73 |
| 53 |
941-3057 |
Bearing, Ball, 20x47x14, 6204 This part replaces 741-3057. Price: $35.46 |
| 54 |
741-3083 |
Bearing, Needle Thrust Price: $14.74 |
| 55 |
748-3094 |
ARM-PTO SELECT Not Available Price: |
| 56 |
750-1223 |
SPACER Not Available Price: |
| 57 |
750-1228 |
SPACER Not Available Price: |
| 58 |
936-0570 |
FLAT WASHER Not Available This part replaces 736-0570. Price: |
| 502198802 |
502198802 |
CYLINDER COVER Price: $27.99 |
| 502212601 |
502212601 |
DECAL 235R Price: $2.74 |
| 502212602 |
537353305 |
DECAL CYLINDER COVER This part replaces 502212602. Price: $2.99 |
| 502212604 |
537353304 |
DECAL CYLINDER COVER This part replaces 502212604. Price: $4.99 |
| 503214425 |
503214425 |
SCREW Price: $3.99 |
| 503906101 |
503906101 |
MUFFLER COVER Price: $22.99 |
