| Ref | Part Number | Description |
|---|
| 1 |
3274-71 |
SCREW-HSH Price: $2.71 |
| 1 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 2 |
532123436 |
ROD,PARK BRAKE Price: $4.99 |
| 3 |
532123437 |
BRKT,PARK BRAKE Price: $4.46 |
| 4 |
532008156 |
FOOT PEDAL COVER Price: $2.64 |
| 4 |
86-5620 |
BEARING-BALL, 2 BOLT FLANGE Price: $103.16 |
| 5 |
532122504 |
BRKT,CLU PEDAL LH Price: $3.08 |
| 5 |
84-1320-03 |
SHAFT-PTO This part replaces 84-1320. Price: $276.98 |
| 6 |
100-2592 |
SCREW-HHF This part replaces 66-9303. Price: $9.09 |
| 6 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 7 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 7 |
819131016 |
WASHER Price: $2.99 |
| 8 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 8 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 9 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 9 |
95-4375 |
DISCONTINUED Price: Call Us |
| 10 |
2412-109 |
CLIP-J Price: $3.82 |
| 10 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 11 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 11 |
532123543 |
ROD,FRT BRAKE Price: $8.38 |
| 12 |
325-14 |
SCREW-HH Price: $2.64 |
| 12 |
532139933 |
CLUTCH/BRAKE PEDAL ASSY Price: $21.38 |
| 13 |
106-1061 |
CLUTCH ADAPTER KIT This part replaces 84-1410. Price: $263.30 |
| 13 |
532123394 |
ROD,CLUTCH Price: $7.99 |
| 14 |
532121978 |
BRKT,LIFT SHAFT Price: $2.38 |
| 14 |
92-5818-03 |
HOUSING This part replaces 92-5818. Price: $554.35 |
| 15 |
532133332 |
ARM, BRAKE ASMBLY Price: $6.71 |
| 15 |
88-1140 |
SPACER-BEARING, LOWER Price: $16.29 |
| 16 |
251-310 |
BEARING-BALL Price: $140.09 |
| 16 |
819251816 |
WASHER T Price: $4.99 |
| 17 |
812000034 |
Ring, Klip Price: $2.99 |
| 17 |
84-0180 |
DISCONTINUED Price: Call Us |
| 18 |
532151332 |
SPRING, BRAKE ROD Price: $4.99 |
| 18 |
84-1540 |
KEY-CLUTCH Price: $18.26 |
| 19 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 19 |
88-1170 |
V-BELT (MATCHED SET) Price: $105.24 |
| 20 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 21 |
532131461 |
CLUTCH KIT This part replaces 532131460. Price: $13.99 |
| 21 |
84-1570 |
SPACER-PLATE Price: $14.75 |
| 22 |
532144585 |
TRUNNION, LEFT Price: $8.99 |
| 22 |
84-1550 |
MOUNT-RUBBER Price: $27.49 |
| 23 |
88-1510 |
SCREW-SPECIAL Price: $9.28 |
| 24 |
3234-22 |
SCREW-HHF Price: $2.69 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 25 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 26 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 26 |
84-1560 |
WASHER-THRUST Price: $2.71 |
| 27 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 27 |
532127369 |
LINK.MOWER.REAR Price: $9.99 |
| 28 |
32128-49 |
NUT-HHF Price: $1.04 |
| 28 |
532140776 |
REAR MOWER LIFT ASSY Price: $40.26 |
| 29 |
325-9 |
SCREW-HH Price: $1.87 |
| 29 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 30 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 30 |
88-1450 |
LOCKNUT-BEARING Price: $32.99 |
| 31 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 31 |
94-5623 |
MAIN HARNESS Price: $1,410.45 |
| 32 |
88-1460 |
WASHER-LOCK Price: $13.85 |
| 33 |
88-1150 |
SPACER-CLUTCH Price: $31.20 |
| 34 |
92-5817 |
PIN-STOP, CLUTCH Price: $18.86 |
| 35 |
88-1280 |
COVER-BELT, LOWER Price: $156.55 |
| 36 |
3256-70 |
WASHER-FLAT Price: $0.25 |
| 37 |
98-7254 |
KIT - CLUTCH REPLACEMENT This part replaces 98-7250. Price: $2,193.47 |
| 38 |
84-1580 |
WASHER-CLUTCH Price: $30.33 |
| 39 |
3234-19 |
SCREW-HHF Price: $1.73 |
| 40 |
86-3040 |
COUPLER-LINE, DRIVE Price: $381.88 |
| 41 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 42 |
86-1990 |
WASHER-THRUST Price: $1.81 |
| 43 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 44 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 45 |
93-9356 |
DECAL-WARNING, BELT Price: $9.78 |
