| Ref | Part Number | Description |
|---|
| 1 |
27-3710 |
DIPSTICK Price: $24.62 |
| 1 |
530026119 |
Duck Bill Valve Price: $1.99 |
| 2 |
3219-2 |
NUT-HEX Price: $0.37 |
| 2 |
530010776 |
Fuel Tank Ass'y. (Inc.1, 3 14 & 15) Price: $3.33 |
| 3 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 3 |
530010797 |
Fuel Cap (Incl. O Ring) Price: $3.33 |
| 4 |
21-8280 |
DISCONTINUED Price: Call Us |
| 4 |
530024651 |
Clamp - Choke Wire Price: $3.33 |
| 5 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 5 |
530015004 |
Screw - #8 - 32 x 5/16" - Choke Rod Clamp Price: $1.99 |
| 6 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 6 |
530019059 |
Seal - Crankshaft Price: $4.99 |
| 7 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 7 |
530015168 |
Screw - #10 - 24 x 5/8" - Crankcase Price: $1.46 |
| 8 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 8 |
530010316 |
Crankcase Assembly (Inc.6, 9 and Qty. 4 of #7) Price: $3.33 |
| 9 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 9 |
530032029 |
Crankshaft Bearing This part replaces 530032058. Price: $7.99 |
| 10 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 10 |
530015351 |
Washer - Crankshaft Thrust Price: $3.99 |
| 11 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 12 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 14 |
21-8080 |
DISCONTINUED Price: Call Us |
| 14 |
530021042 |
Fuel Line Price: $3.33 |
| 15 |
530091878 |
Fuel Pick-Up Ass'y. Price: $5.99 |
| 15 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 16 |
12-5450 |
SCREW Price: $7.99 |
| 16 |
530019112 |
Gasket - Carburetor Case Cover Price: $2.99 |
| 17 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 17 |
530015235 |
Screw - #8 - 18 x 9/16" - Carburetor Case Cover Price: Call Us |
| 18 |
12-8150 |
DISCONTINUED Price: Call Us |
| 19 |
21-7820 |
DISCONTINUED Price: Call Us |
| 19 |
530023373 |
Boot - Throttle - Choke Wire Price: $1.99 |
| 20 |
21-8030 |
DISCONTINUED Price: Call Us |
| 21 |
21-8040 |
DISCONTINUED Price: Call Us |
| 21 |
530069219 |
Engine Gasket Kit This part replaces 530019111. Price: $11.54 |
| 22 |
21-8050 |
BRG SHIM .010 Price: $6.29 |
| 22 |
530024302 |
Piston Ring Price: $6.99 |
| 23 |
21-8060 |
DISCONTINUED Price: Call Us |
| 23 |
530015162 |
Retainer - Wrist Pin Price: $1.99 |
| 24 |
27-6840 |
DISCONTINUED Price: Call Us |
| 24 |
530015126 |
Key - Flywheel Price: $1.99 |
| 25 |
530024902 |
Throttle Wire Price: $3.33 |
| 25 |
99-5691 |
SCREW W/WASHER This part replaces 28-0660. Price: $7.18 |
| 26 |
254-90 |
BEARING-CUP Price: $11.29 |
| 26 |
530019105 |
Seal - Carburetor Case Price: Call Us |
| 27 |
21-8010 |
BRG CONE Price: $30.15 |
| 28 |
32151-83 |
RING-SNAP This part replaces 32120-32. Price: $0.34 |
| 29 |
21-7850 |
PLUG-CUP Price: $23.35 |
| 29 |
530024558 |
Choke Shutter Price: $2.99 |
| 30 |
21-7870 |
DISCONTINUED Price: Call Us |
| 30 |
530015254 |
Wave Washer Price: $1.99 |
| 31 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 31 |
530015404 |
Screw - #10 - 24 x 2-1/8" - Carburetor - Shoulder Price: $2.99 |
| 32 |
530015241 |
Screw - #10 - 24 x 2-1/8" - Reed Valve Price: $1.99 |
| 33 |
21-8070 |
DISCONTINUED Price: Call Us |
| 33 |
530023367 |
Washer - # 6 - Reed Valve Screw Price: Call Us |
| 34 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 34 |
530024438 |
Reed Valve Price: Call Us |
| 35 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 35 |
530019108 |
Gasket - Carburetor Case to Crankcase Price: $2.99 |
| 36 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 36 |
530024409 |
Carburetor Housing Price: $9.99 |
| 37 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 37 |
530019115 |
Carburetor Gasket Price: $3.33 |
| 38 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 38 |
530021043 |
Fuel Line - Carburetor Price: $3.33 |
| 39 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 39 |
530035183 |
Carburetor - See Service Ref. 2. Price: $65.89 |
| 40 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 40 |
530015379 |
Screw - #10 - 24 x 1-7/8" - Carburetor Price: $2.99 |
| 41 |
530015239 |
Screw - #1/4 - 20 x 3/4" - Cylinder Price: $1.99 |
| 42 |
530012070 |
Cylinder Price: $3.33 |
| 42 |
72-9420 |
VENT This part replaces 21-8230. Price: $6.85 |
| 43 |
2811-9 |
FITTING-ELBOW-90 Price: $15.86 |
| 43 |
530024363 |
Diffuser - Muffler Price: $3.33 |
| 44 |
289-38 |
PIPE NIPPLE Price: $21.73 |
| 44 |
530036409 |
Muffler Spring This part replaces 530024903. Price: $1.99 |
| 45 |
530022198 |
Piston Assembly (Inc. 22, 23 & Pin) Price: $3.33 |
| 46 |
530032057 |
Bearing - Wrist Pin Price: $3.28 |
| 47 |
530022202 |
Crankshaft & Rod Assembly Price: $3.33 |
| 48 |
530024362 |
Body Muffler Price: $3.33 |
| 49 |
530024364 |
Screen - Spark Arresting Price: $3.33 |
| 50 |
530024361 |
Cover Muffler Price: $3.33 |
| 51 |
530024932 |
Spring - Muffler Guard Price: $3.33 |
| 52 |
530024855 |
Guard - Muffler Price: $5.99 |
