| Ref | Part Number | Description |
|---|
| 1 |
93-9939 |
TIRE Price: $34.55 |
| 1 |
952030249 |
Spark Plug (RCJ-6Y) This part replaces 952030164. Price: $3.99 |
| 2 |
530015953 |
Screw Price: $1.99 |
| 2 |
68-8950 |
TUBE-INNER (W/VALVE) Price: $26.99 |
| 3 |
530055191 |
Insulator-Heat Price: $1.99 |
| 3 |
93-4241 |
SPACER-BEARING, INNER Price: $26.72 |
| 4 |
120-3366 |
BEARING Price: $28.29 |
| 4 |
530055240 |
Screw Price: $1.99 |
| 5 |
530055241 |
Deflector-Muffler Price: $3.99 |
| 6 |
32128-16 |
NUT-HHF Price: $0.54 |
| 7 |
530016369 |
Bolt-Muffler-external Price: $1.99 |
| 7 |
93-4242 |
PLATE Price: $11.21 |
| 8 |
530016341 |
Screw-Muffler-Internal Price: $0.08 |
| 8 |
93-4239 |
RIM-WHEEL, HALF Price: $29.68 |
| 9 |
93-5980 |
HUB Price: $67.14 |
| 10 |
530071458 |
Gasket-Baffle (Kit) Price: $5.99 |
| 11 |
530071458 |
Gasket-Cylinder (Kit) Price: $5.99 |
| 12 |
530012458 |
CYLINDER This part replaces 530071468. Price: $17.99 |
| 13 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 14 |
530016357 |
Screw-Ignition Module Price: $1.99 |
| 15 |
530035505 |
Ignition Module Price: $29.99 |
| 17 |
530053565 |
Piston Ring Price: $1.28 |
| 18 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 19 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 20 |
530019264 |
Seal-Crankcase Price: $2.99 |
| 21 |
530055728 |
Bearing-Outer Price: $6.99 |
| 22 |
530015941 |
Retainer Ring-C'chaft Price: $1.99 |
| 23 |
530016190 |
Spacer-Flywheel Price: $2.99 |
| 24 |
530015149 |
Washer Price: $1.99 |
| 25 |
530047534 |
FLYWHEEL ASSY This part replaces 530039209. Price: $22.99 |
| 28 |
530032125 |
Bearing-Inner Price: $11.99 |
| 29 |
530012452 |
Assy-Crankshaft Price: $24.99 |
| 30 |
530071458 |
O-ring-C/case (Kit) Price: $5.99 |
| 31 |
530012443 |
Cover-Crankcase Price: $5.99 |
| 32 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 33 |
530071459 |
Foam-219mm (Kit) Price: $4.99 |
| 34 |
530029182 |
Eyelet-Flange Price: $1.99 |
| 35 |
530071467 |
Kit-Rope Price: $4.99 |
| 36 |
530049488 |
Handle-Starter Price: $1.99 |
| 37 |
530016326 |
Screw-Rope Price: $1.99 |
| 38 |
530095355 |
Mulch Blade This part replaces 530095461. Price: $3.99 |
| 39 |
530626605 |
Nut Price: $1.99 |
| 40 |
530402043 |
Spring-Return Cover Price: $2.99 |
| 41 |
530049313 |
Inlet Door Price: $4.99 |
| 42 |
530016240 |
Washer-Belleville Price: $1.99 |
| 43 |
530069817 |
Assy-Impeller Price: $12.99 |
| 44 |
530055106 |
Seal-Ring Price: $1.99 |
| 45 |
530016349 |
Screw Price: $1.99 |
| 46 |
530055101 |
Housing-Pulley Price: $6.99 |
| 47 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 48 |
545150201 |
PULLEY STARTER This part replaces 530071466. Price: $8.99 |
| 49 |
530055102 |
Fan Housing Price: $14.99 |
| 50 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 51 |
530071459 |
Foam-365mm (Kit) Price: $4.99 |
