| Ref | Part Number | Description |
|---|
| 1 |
132-5206 |
ENGINE-KUBOTA, V1505 Price: $6,465.81 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
43-0090 |
SCREW-HH Price: $8.05 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 3 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 4 |
87-5100 |
WASHER-SNUBBING Price: $3.46 |
| 5 |
323-12 |
SCREW-HH Price: $1.14 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 8 |
62-6660 |
SPACER Price: $0.79 |
| 9 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 10 |
115-8066-0P |
MOUNT-ENGINE This part replaces 115-8066-03. Price: $42.18 |
| 11 |
120-3812-03 |
MOUNT-ENGINE Price: $55.51 |
| 11 |
532175370 |
LIFT LINK LH Price: $11.99 |
| 12 |
532175371 |
LIFT LINK RH Price: $11.99 |
| 12 |
99-8343 |
GASKET-MUFFLER Price: $14.99 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
104-2612 |
NUT-HF Price: $0.70 |
| 15 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 15 |
532175562 |
PLATE ASM SUSP FRONT Price: $89.99 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 16 |
93-9164 |
INDICATOR-MINI Price: $55.24 |
| 17 |
106-5277 |
AIR CLEANER ASM Price: $134.07 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
117-5162 |
HOSE-FORMED Price: $101.57 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
117-5164 |
HOSE-FORMED Price: $61.38 |
| 20 |
127-2695-0P |
BRACKET-AIR CLEANER This part replaces 127-2695-03. Price: $29.14 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 21 |
121-5610-0P |
STAND W.A. AIR CLEANER (WELDED) This part replaces 121-5610-03. Price: $170.02 |
| 22 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 23 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
322-9 |
SCREW-HH Price: $3.09 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 25 |
95-5622 |
HANGER-RUBBER Price: $34.18 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 26 |
93-5023 |
SPACER Price: $8.77 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 27 |
94-1416 |
ADAPTER-INDICATOR Price: $11.87 |
| 28 |
108-1785-03 |
BRACKET-SUPPORT, MUFFLER Price: $85.53 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
110-8974-03 |
BRACKET-PIPE, TAIL Price: $19.58 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
108-1782 |
HEADER Price: $95.98 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
114-8897 |
MUFFLER Price: $711.25 |
| 31 |
532176205 |
TRUNNION Price: $6.99 |
| 32 |
2112-9 |
CLAMP Price: $7.78 |
| 32 |
589464902 |
NUT.LIFT LNK.7/16-2 This part replaces 532175994. Price: $3.99 |
| 33 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 34 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 35 |
100-4825 |
BAND-MOUNTING, AIR CLEANER Price: $80.59 |
| 36 |
322-10 |
SCREW-HH Price: $0.70 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
108-1641 |
DRIVESHAFT ASM Price: $717.02 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
110-8976 |
PLATE-SUPPORT, ISOLATOR Price: $4.70 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 39 |
110-0972 |
PULLEY Price: $55.10 |
| 40 |
108-2872 |
COLLAR-FAN This part replaces 104-4247. Price: $21.29 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
110-0966 |
FAN-COOLING Price: $176.79 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 42 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 43 |
33113-025 |
SCREW-HH Price: $1.97 |
| 44 |
98-9676 |
V-BELT Price: $31.01 |
| 45 |
127-2612 |
GUARD-PIPE, TAIL Price: $11.72 |
| 46 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
| 52 |
532175378 |
ARM SUSP. REAR LH Price: $44.99 |
| 53 |
532175802 |
ARM SUSP REAR RH Price: $84.99 |
| 54 |
532175560 |
PIN.FLANGE Price: $11.99 |
