| Ref | Part Number | Description |
|---|
| 1 |
127-3818 |
STARTER ASM Price: $731.59 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
127-3819 |
SWITCH ASM Price: $240.96 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
127-3820 |
ARMATURE ASM Price: $207.90 |
| 4 |
127-3821 |
YOKE ASM Price: $205.19 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
127-3822 |
BRUSH HOLDER ASM Price: $92.97 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
127-3823 |
BRUSH Price: $3.54 |
| 7 |
127-3824 |
BRUSH SET Price: $22.70 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
127-3825 |
SPRING Price: $6.77 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
127-3826 |
COVER ASM Price: $23.25 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
127-3827 |
METAL Price: $33.61 |
| 11 |
127-3828 |
GEAR Price: $22.70 |
| 12 |
127-3829 |
BRACKET Price: $24.30 |
| 13 |
127-3830 |
BRACKET Price: $42.27 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
127-3831 |
GEAR Price: $67.51 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
127-3832 |
BRACKET Price: $3.81 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
127-3833 |
PINION ASM Price: $170.69 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532194746. Price: $34.99 |
| 17 |
127-3834 |
SHAFT Price: $167.40 |
| 18 |
127-3835 |
WASHER SET Price: $15.93 |
| 19 |
127-3836 |
CASE ASM Price: $190.59 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
127-3837 |
METAL-STARTER Price: $7.11 |
| 21 |
127-3838 |
LEVER SET Price: $51.77 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
127-3839 |
DUST COVER ASM Price: $5.83 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
127-3840 |
BOLT-THROUGH Price: $5.94 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
