| Ref | Part Number | Description |
|---|
| 1 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 1 |
532145775 |
DECK SVC KIT 38" This part replaces 532142829. Price: $249.99 |
| 2 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 3 |
3220-3 |
NUT-HJ Price: $0.28 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 4 |
532138440 |
BRKT DECK SW BAR Price: $4.99 |
| 4 |
76-9690-03 |
ROD-BRAKE This part replaces 76-9690. Price: $52.07 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532130832. Price: $9.99 |
| 7 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 8 |
82-5190-03 |
PEDAL-TRACTION Price: $140.00 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 9 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 10 |
63-9751 |
DISCONTINUED Price: Call Us |
| 11 |
532134148 |
BLADE 38" V MULCH Price: $22.99 |
| 11 |
88-1160-03 |
DISCONTINUED Price: Call Us |
| 12 |
3274-19 |
SCREW-HSH Price: $1.42 |
| 12 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $9.99 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 13 |
92-1367 |
LEVER-TRACTION Price: $84.25 |
| 14 |
323-9 |
SCREW-HH Price: $1.29 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
82-4960 |
PAD-FOOT, BRAKE Price: $27.27 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 16 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 17 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 18 |
76-9680 |
HUB-BRAKE Price: $54.35 |
| 19 |
256-90 |
BUSHING-FLANGE Price: $2.92 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
92-5804-01 |
PEDAL-BRAKE, LH This part replaces 92-5804-03. Price: $97.16 |
| 22 |
256-10 |
BUSHING-FLANGE Price: $3.68 |
| 23 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532137607. Price: $2.99 |
| 23 |
92-5805 |
PEDAL-BRAKE, RH Price: $133.73 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
92-2586-01 |
LEVER-BRAKE This part replaces 92-2586-03. Price: $75.15 |
| 25 |
32121-25 |
PIN-ROLL Price: $0.61 |
| 25 |
532123713 |
SPRING TORSION Price: $6.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
92-5806-03 |
DISCONTINUED Price: Call Us |
| 27 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 27 |
532106736 |
SHIELD.DEFLECTOR.MOWER.38.BL Price: $36.99 |
| 28 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 28 |
819111016 |
Washer 11/32 X 5/8 X 16 Ga Price: $5.99 |
| 29 |
323-12 |
SCREW-HH Price: $1.14 |
| 29 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 30 |
76-9030 |
BRAKE SUPPORT ASM Price: $116.55 |
| 31 |
322-21 |
SCREW-HH Price: $4.29 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 32 |
66-1140 |
HUB-ADJUSTMENT Price: $15.52 |
| 33 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 33 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 34 |
63-8410 |
WASHER Price: $1.76 |
| 35 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 36 |
32128-20 |
NUT-HF Price: $0.99 |
| 36 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 37 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 38 |
74-6110 |
STOP-TRACTION Price: $21.73 |
| 39 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 40 |
3218-2 |
NUT-JAM Price: $0.25 |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 41 |
322-4 |
SCREW-HH Price: $0.35 |
| 41 |
532133551 |
PIVOT ROD Price: $6.99 |
| 42 |
93-9423 |
DECAL-SAFETY Price: $62.79 |
| 43 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 43 |
532133504 |
CLUTCH ROD SECONDARY Price: $9.99 |
| 44 |
93-9414 |
DECAL - WARNING Price: $15.33 |
| 45 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 53 |
531165101 |
SERVICE KIT BRAKE ASSEMBLY BRA This part replaces 532130840. Price: $6.99 |
| 54 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 55 |
531164901 |
SERVICE.KIT IDLER ARM This part replaces 532133840. Price: $11.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 67 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 68 |
532144200 |
V-BELT TRIPATH Price: $39.99 |
| 69 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 71 |
531166401 |
SERVICE KIT CLUTCH ROD, CLUTCH This part replaces 532142427. Price: $22.99 |
| 72 |
532131870 |
RETURN SPRING Price: $9.99 |
| 73 |
532127847 |
ARM CLUTCH SECONDARY Price: $2.99 |
| 74 |
532121748 |
WASHER Price: $3.99 |
| 75 |
812000029 |
RING CLIP Price: $3.99 |
| 76 |
532128903 |
BOLT Price: $5.99 |
| 77 |
532127845 |
KEEPER SPRING Price: $4.16 |
| 78 |
532154809 |
ARM ASM CLUTCH PRIMARY Price: $16.99 |
| 79 |
532127498 |
BUSHING.FLANGE.E-RING.GROOVE Price: $4.99 |
| 80 |
532153701 |
SPRING-CLUTCH (2 2 PW01) Price: $4.99 |
| 81 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 82 |
532142028 |
TRUNNION.ADJUSTABLE.3/8-16 Price: $3.99 |
| 86 |
532007631 |
RUNNER LH This part replaces 532125074. Price: $14.99 |
| 87 |
532128772 |
RUNNER.RH.38 Price: $6.99 |
| 88 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 89 |
596140201 |
Washers This part replaces 819131612. Price: $2.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 96 |
874930620 |
Bolt 3/8-16 x 1-1/4 Mulcher Price: $3.99 |
| 97 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 98 |
596134901 |
GSPH This part replaces 819132016. Price: $2.99 |
| 99 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 100 |
532135651 |
WING NUT Price: $3.99 |
| 101 |
532132803 |
COVER.MULCHING.38" (2 2) Price: $54.99 |
| 107 |
532133502 |
SPACER.IDLER.ARM Price: $4.99 |
| 108 |
531150801 |
SERVICE KIT STIFFENER STIFFENE This part replaces 532133503. Price: $6.99 |
| 109 |
874760640 |
Bolt, Hex Head 3/8-16 x 2-1/2 Price: $3.99 |
| 110 |
532142587 |
UPSTOP DECK FRONT 38" Price: $2.64 |
| 113 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 122 |
532131289 |
BRAKE ROD LH Price: $12.99 |
| 123 |
532131288 |
BRAKE ROD RH Price: $6.99 |
| 124 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 128 |
532153390 |
WASHER FELT Price: $3.99 |
| 129 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 130 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 131 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
