| Ref | Part Number | Description |
|---|
| 1 |
117-0959 |
ROLLER-WIEHLE, PLASTIC Price: $366.77 |
| 1 |
817060408 |
Screw, Hex Head, Thread Cutting 1/4-20 x 1/2 (AYP part number) Price: $3.99 |
| 2 |
117-0957 |
SHAFT-ROLLER, WIEHLE Price: $105.15 |
| 2 |
532132752 |
Control, Throttle (AYP part number) Price: $17.99 |
| 4 |
532192334 |
SCREW.SOCKET HD.5/16-1 This part replaces 871070512. Price: $2.99 |
| 5 |
810040500 |
Washer, Lock, Heavy Helical Spring 5/16 (AYP part number) Price: $2.99 |
| 6 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532125593. Price: $7.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 8 |
532121094 |
Bolt, Shoulder 5/16 (AYP part number) Price: $2.99 |
| 9 |
19101216 |
Washer 5/16 x 3/4 x 10 Gauge Price: Call Us |
| 10 |
810040400 |
Washer, Lock, Heavy Helical Spring 1/4 (AYP part number) Price: $3.99 |
| 11 |
874760412 |
Bolt, Hex Hd. 1/4-20 x 3/5 (AYP part number) Price: $3.99 |
| 12 |
532137437 |
Muffler (AYP part number) Price: $179.99 |
| 15 |
532137180 |
Arrester, Spark (Optional Equipment) (AYP part number) Price: $129.99 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 (AYP part number) This part replaces 817490624. Price: $3.99 |
| 20 |
873510600 |
Nut, Keps, Hex 3/8-16 (AYP part number) Price: $3.99 |
| 21 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
