| Ref | Part Number | Description |
|---|
| 1 |
132748 |
SUB= 532132748 Price: Call Us |
| 1 |
60-6190 |
O-RING Price: $3.76 |
| 2 |
17720410 |
SCREW LT Price: Call Us |
| 2 |
95-6050 |
PIN-DOWEL Price: $2.59 |
| 3 |
42D707 |
ENGINE, BRIGGS Price: Call Us |
| 3 |
60-6250 |
WASHER Price: $9.70 |
| 4 |
149723 |
MUFFLER.TW.LOTONE Price: Call Us |
| 4 |
76-7010 |
RING-RETAINING This part replaces 60-6260. Price: $3.66 |
| 5 |
144069 |
EXHAUST.B&S.18.LH Price: Call Us |
| 5 |
60-6270 |
RING Price: $2.40 |
| 6 |
144068 |
EXHAUST.B&S.18.RH Price: Call Us |
| 6 |
60-6330 |
SCREW Price: $6.91 |
| 7 |
138129 |
CLAMP.TUBE.DBL.EN Price: Call Us |
| 8 |
150176 |
BOLT.5/16-18.UNC Price: Call Us |
| 10 |
145552 |
SHIELD.HEAT. Price: Call Us |
| 10 |
60-6120 |
COVER-SEAL Price: $17.87 |
| 11 |
10040400 |
LOCKWASHER Price: Call Us |
| 11 |
60-6010 |
COVER-TRUNNION Price: $11.26 |
| 12 |
74780412 |
SUB= 74780414 Price: Call Us |
| 12 |
99-8702 |
O-RING COVER Price: $64.56 |
| 13 |
272250 |
GASKET MUFFLER Price: Call Us |
| 13 |
60-5990 |
RACE Price: $51.48 |
| 14 |
13280336 |
PIPE NIPPLE LT Price: Call Us |
| 14 |
60-6110 |
BEARING Price: $47.19 |
| 15 |
13200300 |
ELBOW Price: Call Us |
| 15 |
60-6130 |
GASKET Price: $19.03 |
| 16 |
11050600 |
LOCKWASHER Price: Call Us |
| 16 |
76-6950 |
RACE-THRUST This part replaces 60-6160. Price: $25.65 |
| 17 |
17490624 |
SCREW LT Price: Call Us |
| 17 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 18 |
60-6230 |
SCREW-HH Price: $4.80 |
| 19 |
60-6220 |
SCREW-HH Price: $5.33 |
| 20 |
105-3331 |
SEAL-SHAFT This part replaces 60-6300. Price: $35.63 |
| 21 |
104-4861 |
SEAL-SHAFT This part replaces 42-2720. Price: $28.44 |
| 22 |
68-6460 |
RELIEF VALVE KIT Price: $545.19 |
| 23 |
156123 |
SHIELD-HEAT Price: Call Us |
| 23 |
99-8703 |
HOUSING ASM Price: $819.08 |
| 25 |
99-8705 |
BACKPLATE ASM Price: $1,560.57 |
| 26 |
99-8704 |
PLATE-VALVE Price: $457.47 |
| 27 |
60-6140 |
SHAFT Price: $420.62 |
| 28 |
60-6020 |
CAMPLATE Price: $784.96 |
| 29 |
137180 |
SUB= 532137180 Price: Call Us |
| 29 |
60-6200 |
ADAPTER Price: $537.89 |
| 30 |
99-8706 |
GEROTOR-INNER Price: $153.64 |
| 31 |
107-4445 |
DISCONTINUED This part replaces 99-8707. Price: $568.49 |
| 31 |
151346 |
TANK FUEL REAR Price: Call Us |
| 32 |
140527 |
CAP ASM FUEL Price: Call Us |
| 32 |
60-6280 |
PLUG Price: $24.83 |
| 33 |
123487X |
HOSE CLAMP Price: Call Us |
| 34 |
106082X |
PAD-SPACER LT Price: Call Us |
| 34 |
60-6320 |
KEY Price: $5.45 |
| 35 |
17490512 |
SCREW Price: Call Us |
| 35 |
99-8708 |
O-RING Price: $21.71 |
| 36 |
60-6240 |
WASHER Price: $15.20 |
| 37 |
60-6310 |
KEY Price: $8.97 |
| 37 |
8543R |
FUEL LINE T Price: Call Us |
| 38 |
3256-73 |
WASHER-FLAT Price: $1.31 |
| 39 |
109227X |
PAD IDLER TI Price: Call Us |
| 39 |
95-6056 |
SEAL KIT Price: $111.09 |
| 40 |
3645J |
BUSHING OUTLET T Price: Call Us |
| 41 |
139277 |
STEM.TANK.FUEL Price: Call Us |
