| Ref | Part Number | Description |
|---|
| 1 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 1 |
817060408 |
SCREW Price: $4.99 |
| 2 |
121-5631 |
HUB ASM Price: $156.48 |
| 2 |
532133025 |
CONTROL.TH/CH.RH.BLK.FLG.EEC Price: $24.99 |
| 3 |
136-7963 |
TIRE ASM Price: $455.76 |
| 4 |
115-5103 |
SCREW-HHF Price: $0.34 |
| 4 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 5 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 5 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 6 |
325-12 |
SCREW-HH Price: $2.27 |
| 6 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED Price: $8.99 |
| 7 |
147-3594 |
ADAPTER-BRAKE This part replaces 120-6253-03. Price: $47.56 |
| 7 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 8 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 9 |
117-3290 |
NUT-HEX Price: $32.02 |
| 9 |
734115441 |
WASHER - 26X6.5X1.6 This part replaces 819101216. Price: $0.99 |
| 10 |
114-8864 |
DRUM-BRAKE Price: $248.55 |
| 10 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 11 |
127-2741 |
SHIELD-WHEEL, FRONT Price: $9.99 |
| 12 |
127-2742 |
SHIELD-WHEEL, REAR Price: $8.07 |
| 12 |
532137437 |
MUFFLER.SINGLE.B&S.12HP Price: $199.99 |
| 13 |
532101326 |
DEFL MUFFLER LTV Price: $4.01 |
| 14 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 15 |
139-5952 |
LH BRAKE ASM This part replaces 120-6261. Price: $449.41 |
| 15 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 16 |
139-5951 |
RH BRAKE ASM This part replaces 120-6260. Price: $449.41 |
| 16 |
532127951 |
STOP THROTTLE Price: $2.52 |
| 17 |
323-4 |
SCREW-HH Price: $1.02 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 18 |
322-7 |
SCREW-HH Price: $0.89 |
| 20 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 21 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 22 |
120-6267 |
CLIP-SPRING, LH Price: $6.99 |
| 23 |
120-6266 |
CLIP-SPRING, RH Price: $6.99 |
| 24 |
87-4020 |
SPRING-EXTENSION Price: $17.01 |
| 25 |
3218-2 |
NUT-JAM Price: $0.25 |
| 39 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 532128861. Price: $2.99 |
