| Ref | Part Number | Description |
|---|
| 1 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 1 |
731-3100A |
VALVE HANDLE Not Available Price: |
| 2 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 2 |
910-0749 |
CHAIN ADJUSTMENT BOLT Not Available This part replaces 710-0749. Price: |
| 3 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 3 |
712-0998 |
Nut, Hex Center Lock, #10-24 Not Available Price: |
| 4 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 4 |
913-3000 |
CHAIN LINK Not Available This part replaces 713-3000. Price: |
| 5 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 6 |
3258-19 |
SCREW Price: $0.42 |
| 6 |
703-1802 |
SINGLE CLAMP Not Available Price: |
| 7 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 7 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 8 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 8 |
710-3218 |
Screw, Socket Hd Cap, 1/4-20 X .62 Lg GR8 Price: $3.86 |
| 9 |
727-3066 |
Tube Assy, Return Price: $182.90 |
| 10 |
62-6300 |
SLEEVE ASM Price: $31.93 |
| 10 |
921-3021 |
O-RING .301 IDX.070 This part replaces 721-3021. Price: $3.39 |
| 11 |
33-1270 |
BOWL-CLEAR Price: $10.91 |
| 11 |
727-3067 |
Tube Assy, Pressure Price: $86.36 |
| 12 |
33-1260 |
COVER ASM Price: $36.59 |
| 12 |
727-3068 |
Tube Assy, Adapter Price: $40.11 |
| 13 |
43-3810-03 |
TUBE-CLEANER, AIR This part replaces 43-3810. Price: $89.59 |
| 13 |
727-3012 |
Elbow, Tube, 90 Degree Price: $23.35 |
| 14 |
903-1803 |
VALVE DOUBLE CLAMP Not Available This part replaces 703-1803. Price: |
| 15 |
727-3046 |
CYLINDER HOSE Not Available Price: |
| 16 |
727-3045 |
CYLINDER HOSE Not Available Price: |
| 17 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 18 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 19 |
710-0641 |
Screw, Hex Cap, 1/4-20 X 2.25 Lg Price: $3.66 |
| 20 |
703-1801 |
VALVE MOUNTING BRACKET Not Available Price: |
| 21 |
712-3006 |
HEX NUT Price: $4.05 |
| 23 |
721-3002 |
O-RING-1/4 Not Available Price: |
| 26 |
703-1802 |
SINGLE CLAMP Not Available Price: |
| 27 |
717-3331 |
VALVE-RELIEF Not Available Price: |
